• Model NO.：CLW5042TSLB
• Use：Stainelss Steel
• Cleaning Process：Cold Water Cleaning
• Condition：New
• Purpose：Road Sweeping,Street Cleaning
• Sweeping Width：3.5meter
• Dust Container：1.7cbm 1.7m3 1700L
• Brush：4 Brushes, 1 at Each Side
• Auxiliary Engine：Jmc Engine 77HP
• Garbage Container Sweeping System：Automic Water Cleaning
• Max. Suction Particle：Diameter 120mm
• Sweeping Speed：13000m2,H ~ 52000m2,H
• Water Container：800liters 800L 0.8cbm 0.8m3
• Function：Road Sweeping,Road Cleaning
• High Pressure Cleaning：20meters High Pressure Tube
• Suction Pan：1 Unit with 2 Hose
• Garbage Discharging：Tipping System,Dumping System
• Brush Function：Automatic Retreating for Collision
• Transport Package：Naked Packing
• Specification：Water 9000liters Dust Bin 7cbm
• Trademark：CLW
• Origin：Suizhou, China
• HS Code：8705909990
• Production Capacity：500 Unit,Month

 CabinDriving type 4x2  RHD or LHD single row,with two seat,with A/CVehicle Main DimensionsOverall dimensions (L x W x H)mm5560×1760×2280Wheel base  (mm)2600Wheel track  (front/rear) (mm)1680/1640Approach/Departure angle(°)20/13Weight in KGSTare Weight3880payload284Overall Weight4294Front axles loading capacity1x1717Rear axles loading capacity1x2577EngineBrandQuanchai  Model4A2-68C50Horse Power(HP)68HPEmission standardEuroVGearboxMechanical 5 forwards & 1 reverse with Synchronizer,Manual TypeSteeringLHD or RHD Tire6.00R15LT,6 tires with one spareDriving Type4X2 Rear Axle DriveSuspension TypeSteel Plate SpringSteel Spring No. (F/R)8/10+7Brake TypeDouble circuit pneumatic brake, drum typeBraking Length(Full Load 30km/h)≤10mMax. driving speed(km/h)99Min. Radius of Turning Circle(m)8Max. Grade-ability≥30%Fuel Consumption of EngineDriving(L/100km)Working(L/h)Working(L/10000cbm)≤12≤6≤3Special Function PartsWater tank700 Liters,4mm Stainless SteelGarbage Hopper2.5cbm,4mm Stainless Steel,with high pressure self-cleaning device for cleaning garbage hopperCleaning Width (mm)2800~3200Sweeping Speed(km/h)3~15 km/hWashing speed(km/h)15~20km/hMax. Cleaning Capacity48000m2/hSuction CapacityDensity(g/cbm)2.0Weight(kg)1.5Suction granularity(mm)≥100Dumping angle≥45°Sweeping Efficiency≥96%Working Noise(db)<88 according with GB7258 regulation

Products Catalog:

1. LPG Tank Truck Trailer/ Fuel Tanker Truck/ LPG station
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck /Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truc
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
