• Model NO.：CLW5087ZYS
• Use：Stainless Steel 304
• Cleaning Process：Cold Water Cleaning
• Condition：New
• Sweeping Speed：3-20 Km,H
• Maximum Cleaning Capacity：40000 Cbm,H
• Water Tank：1.5 Cbm, Stainless Steel 304
• Motor：SANYO
• Fan：Maintenance-Free Centrifugal Fan(Vacuum Tube, and
• Operation Manual：1 Set for Each Customer
• Maximum Sweep Width：2.8m
• Auxiliary Engine：Jmc, 77HP
• Dust Tank：4.0 Cbm, Stainless Steel 304
• Pump：Electronic Water Pump, Chinese Famous Brand.
• Sweeping Brushes：4 , 2 Sweeping Brushes on Each Side
• Color：as Per Customer Requirements
• Transport Package：Roll-Roll, Bulk Shipment
• Specification：5950*2000*2500 (mm)
• Trademark：CLW
• Origin：Suizhou, China
• HS Code：8701909000
• Production Capacity：500 Unit,Month

General Technical ParametersOverall Dimension5950X2000X2500 (mm)Gross Vehicle Weight8000(Kg)Curb Weight2300(Kg)Chassis SpecificationChassis BrandSinotruk HowoDrive model4*2CabinHowo 1880 single row, LHD, with air condition.Number of Passengers2EngineModelCY4100ZLQ/95HP, 4-stroke direct injection , 4-cylinder in-line, turbocharged intercooled, with ABS.Power70KW/95HPEmission standardEURO 2Displacement3707(ml)Fuel typeDieselGearboxWLY6T100, 6Forwards & 1Reverse, manual operation, with power steering.Brake SystemOil breakWheel Base3360mmFront/Rear Axle Loading2000/3500(Kg)OverhangMechanical Suspension, 11/9+7HTire7.00R16, steel wire tire, 6pc with 1 spare tireSweeping Speed3-20 km/hUpperstructure SpecificationTankWater TankMaterialStainless steel 304Volume1.5(cbm)Dust TankMaterialStainless steel 304Volume4(cbm)Auxiliary EngineModelJMCPower57KW/77HPMaximum sweep width2.8mMaximum cleaning capacity40000m³/hStandard Configuration1. Equipped with 2 sweeping brushes on each side;2. Equipped with Sanyo Motor;3. Equipped with HIP-SD-7 electromagnetic valve set;4. Equipped with continuously variable speed automatic clutch;5. Equipped with German Schneider control switch;6. Equipped with maintenance-free centrifugal fan, vacuum tube, and rear suction device;7. Equipped with electronic water pump(water-spray nozzle to restrain dust), and manual pump emergency system;8. Equipped with hydraulic system(control box lift, rear door open);9. Equipped with rear LED arrow lights;10. User's operation manual 1 set.Optional ConfigurationFront flush, rear sprinkler, side sprayer, self-cleaning function of dust tank, hose reel with water gun, foggy gun, reversing image monitoring, snow shovel, foggy gun, aerial work platform color is optional, etc.
