• Model NO.：CLW5087SLC
• Use：Stainless Steel 304
• Cleaning Process：Cold Water Cleaning
• Condition：New
• Sweeping Speed：3-20 Km,H
• Maximum Cleaning Capacity：4000 Cbm,H
• Water Tank：3.5 Cbm, Stainless Steel 304
• Motor：SANYO Brand
• Operation Manual：1 Set for Each Customer
• Maximum Sweep Width：3.5m
• Engine：Cummins, 140HP
• Dust Tank：8 Cbm, Stainless Steel 304
• Color：as Per Customer Requirements
• Pump：Electronic Water Pump, Chinese Famous Brand.
• Sweeping Brushes：4 , 2 Sweeping Brushes on Each Side
• Fan：Maintenance-Free Centrifugal Fan(Vacuum Tube, and
• Transport Package：Roll-Roll, Bulk Shipment
• Specification：7800*2470*3100 (mm)
• Trademark：CLW
• Origin：Suizhou, China
• HS Code：8705909990
• Production Capacity：500 Unit,Month

General Technical ParametersOverall Dimension7800*2470*3100 (mm)Gross Vehicle Weight9550(Kg)Curb Weight3300(Kg)Chassis SpecificationChassis BrandDongfengDrive model4*2Cabinsingle row, LHD, with air condition.Number of Passengers2EngineModelCummins/180HP, 4-stroke direct injection , 4-cylinder in-line, turbocharged intercooled, with ABS.Power132KW/180HPEmission standardEURO 3Displacement5750(ml)Fuel typeDieselGearbox8Forwards & 1Reverse, manual operation, with power steering.Brake SystemAir breakWheel Base4500mmFront/Rear Axle Loading5000/10000(Kg)OverhangMechanical Suspension, 11/9+7HTire10.00R20, steel wire tire, 6pc with 1 spare tireSweeping Speed3-20 km/hUpperstructure SpecificationTankWater TankMaterialStainless steel 304Volume3.5(cbm)Dust TankMaterialStainless steel 304Volume8(cbm)Auxiliary EngineModelCumminsPower103KW/140HPMaximum sweep width3.5mMaximum cleaning capacity40000m³/hStandard Configuration1. Equipped with 2 sweeping brushes on each side;2. Equipped with Sanyo Motor;3. Equipped with HIP-SD-7 electromagnetic valve set;4. Equipped with continuously variable speed automatic clutch;5. Equipped with German Schneider control switch;6. Equipped with maintenance-free centrifugal fan, vacuum tube, and rear suction device;7. Equipped with electronic water pump(water-spray nozzle to restrain dust), and manual pump emergency system;8. Equipped with hydraulic system(control box lift, rear door open);9. Equipped with rear LED arrow lights;10. User's operation manual 1 set.Optional ConfigurationFront flush, rear sprinkler, side sprayer, self-cleaning function of dust tank, hose reel with water gun, foggy gun, reversing image monitoring, snow shovel, foggy gun, aerial work platform color is optional, etc.
