• Model NO.：CLW5120GB
• Use：Stainless Steel
• Cleaning Process：Cold Water Cleaning
• Condition：New
• Truck Chassis Brand：Dongfeng
• Water Tank：1m3, 1.5m3, 2m3, 4cbm
• Material：Stainless Steel
• Hand Driving：LHD or Rhd
• Max. Working Width：3500mm
• Delivery Time：30 Days
• Dust Bin Capacity：4cbm, 6cbm, 7m3, 8m3, 12m3
• Drive Model：4X2
• Operation：Self-Loading and Discharge
• Max. Operation Ability：70000m2,H
• Auxiliary Engine：Dongfeng Brand
• Warranty：1 Year
• Transport Package：Bulk Shipment, RO-RO
• Specification：10cbm
• Trademark：CLW
• Origin：Suizhou, China
• HS Code：87059099
• Production Capacity：400pieces,Unit

ChassisDrive Model4X2, Left hand driveVehicle Main DimensionsDimensions(L x W x H)(mm)8450*2500*3100Wheel base (mm)4700Overhang (front/rear) (mm)1015/1815Wheel track (front/rear) (mm)1504/1425Approach/Departure angle(°)24/13Weight in KGSCurb Weight (kg)10000Front/Rear axle loading(kg)4500/9000Max. driving speed(km/h)110EngineBrandCumminsHorse Power(HP)180Displacement (ml)6700Emission standardEuro IVGearbox5 forwards & 1 reverseSteering GearPower steering, hydraulic steering with power assistanceBrakesAir brakeTire900R20 tire , 6 + 1(spare tire)Upper & EquipmentTankGarbage tankTank materialStainless steel 304Tank volume(cbm)8.0 cbmWater tankTank materialStainless steel 304Tank volume(cbm)2.0 cbmOperation detailMax. Operation ability(m2/h)70000Max. Sucking dimension(mm)50Auxiliary engineModelISUZU BrandQuantity(No.)1Power(kw)68BlowerQuantity(No.)1BrandChina famous brandPower(kw)18Speed(r/min)2900Vacuum cleanerMain Vacuum cleanerQuantity(No.)1Width(mm)1800Side Vacuum cleanerQuantity(No.)2Width(mm)600Max. Working width(mm)3500Sucking Nozzle wheelQuantity(No.)4HeightAdjustableRemarks

1. Rear LED pilot lamp
2. Self unloading box body
3. The color will be designed on basis of your requirements.
