Iveco 6X4 380HP Concrete Mixer Truck 2021 Trucks
Qingdao Seize The Future Automobile Sales Co., Ltd.- Certification：ISO9000, CCC, TS16949, RoHS, CE
- Transmission Type：Manual
- Emission Standard：Euro III
- Displacement：9
- Payload：30T
- Fuel：Diesel
Base Info
- Model NO.：CQ1254HTG384
- Drive Mode：6x4
- Maximum Horsepower：300-400hp
- Condition：New
- Colour：I Veco Concrete Mixer Truck
- Brand：Iveco
- Engine：380HP Horsepower
- Wheels：6X4
- Name：Concrete Mixer Truck
- Model：Cq1254htg384
- Transport Package：Nude or Any Needs of The Cliets
- Specification：CE, SGS and VE
- Trademark：Iveco
- Origin：Chongqng, China
- HS Code：89690666
- Production Capacity：10000PCS,Year
Description
Model
CQ5254GJBHTG384
Driving type
6X4 LHD
Driver's cab
C100 Short cabin, one sleeper with A/C
Dimensions(mm)
Wheel base(mm): 3800+1400
Overall size(mm): 9125x2500x3950
Engine
Maker: CURSOR
Diesel 4 stroke direct injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & intercooling
Engine model: F2CE0681C*B052(C9 340)
Emission Standard: EUROIII
Maximum output: 340HP /2200 rpm
Number of cylinder: 6
Displacement: 8.709L
Clutch
430mm, hydraulically operating with air assistance
Transmission
FAST Brand RT-11509C(9 speeds)
Rear Axle
Genlyon, 16T double reduction drive axle
Ratio: 4.8, 5.73, 6.72
Frame(mm)
865/317 8+8
Types
12.00R20 Radial tyre
Electrics
Operating voltage: 24V, negative grounded
Weight(kg)
Kerb weight 12980
Total weight 25000
Maximum driving speed(km/h)
80
Fuel tank(L)
400
Mixer Drum
HYD drive system
Decelerator:Italy TOP P68
Pump: 089
Motor
Drum specifications
Mixing volume:4--6m3
Gradient:13
Rest rate:1%
Rotational speed:0-14r/min
Hydraulic system
Total hydraulic system
