• Model NO.：CA5310GJBJS306
• Drive Mode：8x4
• Maximum Horsepower：300-400hp
• Condition：New
• Volume：6,8,9,10
• Truck Type：Agitator Truck
• Truck Condition：Brand New
• Driving Type：6X4
• Steering：LHD, Rhd
• Color：Red, White
• Transport Package：Nude Packing
• Specification：ISO
• Trademark：FAW
• Origin：China
• HS Code：8705909990
• Production Capacity：300PCS, Month

The total mass
31000
Curb Weight
14800
Rated the quality of
10005,10070
Chassis Model
CA5310GJBP1K2T4
Dimensions(mm)
9950,9650*2500*3995
Wheelbase
4300+1350+1350
Number of axes
4
Axle load
7000/18000
Tire Specifications
11.00-20 16PR,11.00R20 16PR,12.00-20 16PR,12.00R20 14PR
Number of tires
12
Emission standards
Euro2,3,4
Type of fuel
Diesel
Engine Model
Engine Manufacturer
Engine displacement
Engine power
WP10.380E32
WEICHAI
9726(ml)
279(kw)
 Parameters of mixing drumagitation volume (m3)4charging rate (m3/min)≥2.8discharging rate (m3/min)≥1.2residual rate (%)≤0.5rotating speed of mixing drum (rpm)0~12Driving systemspeed reducermade in Chinahydraulic pumpmade in Chinahydraulic motormade in Chinaradiatormade in ChinaWater supplywater tank volume (L)400type of water supplyair pressure water supplyControl systemcontrol modeconnecting rod controlstructure features1,mixing drum and mixer blade using special
wear-resisting material Q345, mixing drum material thickness is 4mm,mixer blade material thickness is 3mm.2, material of blowpit and feed hopper scaleboard is just the same as the mixing drum;3,humanizing operating system,connecting rod operation,concise safe and reliable;4,using imported brand-name hydraulic system;5,flushing water back control;6,product with quick discharging, no residual
