• Model NO.：ZZ1257N3847C
• Drive Mode：6x4
• Maximum Horsepower：>400hp
• Condition：New
• Engine：Wd615.47
• Gearbox：Hw19710
• Steering：Zf, LHD, Rhd
• Drum Capacity：8 Cubic
• Transport Package：Nude Packing
• Specification：8 Cubic Meters
• Trademark：HOWO
• Origin：China
• HS Code：8704230090
• Production Capacity：5000 Unit,Year

Model
Specification
Item
Unit

Drum specification



Material:

T520JJ
Geometric volume of the drumM³
13
Effective mixing volumeM³
8
Gradient of the drumAngle
15°
Charge rate
64.5%
Discharging remainder rate
< 1%
Rotational speed of the drumr/min
0-18
Discharging capacity
SlumpCM
About     5-22cm
Discharging speedM³ /min
About 1.5-2.7
Hydraulic

drive system
Pump




Model
HYDROSLA  /  EATON
Max displacementMpa/ml/r
35/89
Motor


Model
HYDROSLA  /  EATON
Max displacementMpa/ml/r
35/89
Decelerator


Model
PMB6.5sp
Ratioi
120.3
Water

supply system
Supply style
Air pressure system
Volume of water tankL
400


Parameter

of chassis


Chassis model
ZZ1257N3847C
Wheelbasemm
3800
Others
Gear box
HW19710
Cab  HW76

Steering ZF8118

front axle HF9

drive axle HC16

Air conditioner
Tyre
12.00R20
Tread  front/rearmm
2010/1847/1847
Max speedKm/h
83
Min turning diameterm
Less than 20
Min ground clearancemm
250
Engine


Engine model
SINOTRUK ENGINE WD615.95E (EGR)EURO 3
Max horsepowerhp
320
Max torqueN. m/rpm
1425/1300
Fuel consumption per 100kmL/100km
Less than 30
Weight


Kerb weightkg
13580
Max payloadkg
11225
Total weightkg
25000
Appearance dimensions (L*W*H)mm
8920*2495*393
