• Model NO.：ND52500GJBZ
• Drive Mode：6x4
• Maximum Horsepower：300-400hp
• Condition：New
• Engine：Weichai Wp10.340e32 340HP
• Cab：Long Cabin, Single Sleeper, A,C
• Transmission：Fuller
• Steering：Tas85
• Mixing Body：10 Cbm Mixer Body
• Power：Diesel
• Truck Type：Mixer Truck
• Tire Design：Bias
• Seats：≤5
• Transport Package：Nude Packing
• Specification：ISO, CCC
• Trademark：North benz
• Origin：China(Mainland)
• HS Code：87054000
• Production Capacity：30000 Per Year

                                 SPECIFICATION                  NORTH BENZ 6x4 MIXER TRUCKTraction6x4Driving typeLHD (right hand drive is optional)CabinNorth Benz, long cabin, single sleeper, A/C, made by full steel material, 4 point suspension, anti-crash performance can be ensured by double hollow chamber structure, Can be tipped forwardly,
high back and shock absorption seat for the driver, sun protection, Dash board with all necessary
gauges such as (km meter, rpm, oil pressure, temperature, air pressure, fuel level), Radio player(with MP3 fuction).
 Major color of cab: Ice white lacquer+ color barVehicle Main DimensionsLxWxH(mm)9405×2500×3980
 Wheel base(mm)3800+1450
 Wheel track(front/rear)(mm)Front track (mm): 1995
Rear track (mm): 1800
 Approach/Departure angle(°)23/20
 Overhang (front/rear)(mm)1515/2640Weight
in KGSTare Weight(kg)13785kg
 Total mass(kg)25000kg
 Front axle loading capacity7.5tons
 Rear axle loading capacity2x13tons
 Ratio1:5.263Driving Speed(km/h)
 90EngineBrandWei chai
 ModelWP10.340E32
 EmissionEuro III EGR
 Engine typeDiesel 4-stroke direct injection engine, 6-cylinder in-line
with water cooling, turbo-charging & intercooling
 Displacement9.726 L /Diesel
 Max. output340hp@2200rpm
 Max torque1250NM@1400-1600rpm
 Bore/Stroke(mm)126/130
 PTOYesGear boxModel9T-160
 BrandBei ben
 Type9 forward gears, 1 reverse gear, manual, made in China
 ClutchΦ430 Diaphragm type, Single dry frictional disc, Hydraulic boostingSteeringZF8098(Germany technology)TyreTyre12.00-20 Bias tyre
 No. of tyres10+1spareFuel tank300L  Aluminium TankFront axleMercedes Benz Technology
 Rear axleMercedes Benz Technology, Double reduction driving axle with inter-wheel differential and differential lockFrameMercedes-Benz technology, aequilate main frame,300x90x8+6+8mmSpring10/13Gradability30degreeBrake systemDouble-circulate brake system

Mixing Body   capacity

10 cbm
