• Model NO.：ZZ1317N466GE1
• Bearing Capacity：Medium
• Car Type：Van
• Condition：Used
• Transport Package：Nude Packing
• Specification：standard size
• Trademark：SINOTRUK
• Origin：China
• HS Code：870190900
• Production Capacity：5000PCS,Month

   ProductHOWO 8x4 refrigerated truckGross weight (kg)31000Overall dimensions12000*2550*4000Loading weight(kg)17890Cargo Dimension9420*2330*2490Curb weight(kg)12980Allowable passengers in cab2,3Approach/Departure Angle(°)19 /14Front / rear suspension(mm)1430/2820Number of axles4Wheelbase (mm)1800+3800+1350Axle-load(Kg)6500/7000/17500Max speed(km/h)110Chassis parameters   Chassis modelZZ1317N466GE1  BrandHOWO  Overall dimensions10870*2496*3035Tire number12Approach/Departure Angle(°)19/19Tire specification295/80R22.5Number of Spring leafs2011/11/10Front tread(mm)2015/2015Fuel typedieselRear tread(mm)1830/1830Emission standardEuro 3-5Engine model Displacement(ml)Power(kw)MC07.28-30 6870206otherswith air conditionerRefrigerated Truck Body SpecificationRefrigerated truck bodies adopt FRP sheet in two sides and Polyurethane foamin the core. The truck bodies equipped with double rear door in back. Without side door.

 FAQ

Q1: I don't want this Dimension

A: The Dimension can be toatal customized.

Q2: Minimum order quantity?

A: MOQ is 1 unit.

Q3: Production period?

A: Within 25 days since the moment we got your down payment. Except for large orders.

Q4: Payment term?

A: 50% T/T should be paid before delivery. Except for large orders.

Q5: Shipping?

A: By international courier service, such as DHL, TNT, UPS, or Fedex.

Warranty
(1) One year quality guarantee or within 100000km, which comes the first.
(2) Other spare part could be supplied by OEM at cost prices.
(3) Regularly callback to know the vehicle's working status.
(4) The overseas engineers are always ready to deal with unexpected needs.
Our Advantages
(1)Competitive Factory Price and Excellent Quality
(2)More than 20 years' experience as a manufacturer
(3)Products Quality Certification SGS CCC ISO
(4)Perfect after-sale service
(5)Customized products available with us
(6)Export to more than 50 countries and regions
