HOWO 9cbm Concrete Mixer Truck Cement Transportation Truck
Shandong Shanglong Economic and Trade Corporation Ltd.- Certification：ISO9000
- Transmission Type：Manual
- Emission Standard：EU 2,3,4
- Displacement：9.726L
- Payload：20T
- Fuel：Diesel
Base Info
- Model NO.：ZZ1257N3841W
- Drive Mode：6x4
- Maximum Horsepower：300-400hp
- Condition：New
- Power：Diesel, 371HP
- Drive：6X4 (8X4 Is Available)
- Steering：Left Hand Drive (Rhd Is Available)
- Cabin：Long Cabin with One Bunk (No Bunk Is Availoable)
- Emission：Euro 2 (Euro 3, Euro 4 Is Available)
- Dimension(L*W*H)：8715X2496X3850
- Gross Vehicle Weight：25000kg
- Tire Design：Bias or Radial
- Cubage：9m3
- Warranty Period：One Year
- Transport Package：Nude Packing
- Specification：Standard
- Trademark：SINOTRUK
- Origin：China
- HS Code：87054000
- Production Capacity：300 Sets , Month
Description
Type
9cubic meters concrete /cement mixer truck
Chassis model
ZZ1257N3847
Dimension
9335×2496×3980mm
Rated loading capacity
11850kg
Wheel base
3800+1350mm
Tire specification
12.00-20(11pcs)
Engine model
WD615.69(sino truck brand)
Power
336HP
Emmission standard
Euro 2
Fuel material
Diesel
Max speed
90km/h
Feeding speed
≥3m3/min
Output speed
≥2m3/min
Speed reducer
Import from italy
Water box capacity
300L
8m3concrete mixer
Italy PV089 pump, MF089motor, 6SP Gearbox, China 12R radiator
9m3concrete mixer
Italy PV089 pump, MF089motor, TOP P68 Gearbox, China
12L radiator
10m3concreter mixer
Italy PV089 pump, MF089motor, TOP P68 Gearbox, China 12L Radiator
11-12m3concrete mixer
Italy PV089 pump, MF089motor, TOP P75 Gearbox, China 12L Radiator
14m3 concrete mixer
Italy PVA090 pump, MF090motor, TOP P75R or P80 Gearbox, China 25L or 26L Radiator
16m3 concrete mixer
Italy PVA090 pump, MF090motor, TOP P80 Gearbox, China 25L or 26L Radiator
Mixer body material
5mm or 6mm steel plate
