• Model NO.：CA1120
• Drive Wheel：4x2
• Hoesrpower：150-250hp
• Condition：New
• Max Payload：10000
• Material：Steel
• Scale：Medium Duty
• Brand：FAW
• Driving：4X2
• Steering：LHD, Rhd
• Transport Package：Nude Packing
• Specification：ISO
• Trademark：FAW
• Origin：Shandong
• HS Code：8704223000
• Production Capacity：500 Unit,Units , Month

Basic Info.

Model NO. CA1120 Drive Wheel 4x2 Hoesrpower 150-250hp Condition New Max Payload 10000 Material Steel Scale Medium Duty Brand FAW Driving 4X2 Steering LHD, Rhd Transport Package Nude Packing Specification ISO Trademark FAW Origin Shandong HS Code 8704223000 Production Capacity 500 Unit/Units / Month

Product Description

10m3 sewage suction truck/ 4x2 sewage vacuum suction truck

5-10 cbm sewage truck,Vacuum Suction Truck,suction sewage truck

Company information:
We're one professional manufacturer which refitting special truck and trailer in China, established in 1969, more than 40 yrs producing experience, a growing enterprise with endless innovations and development. Our corporation mainly specializes in the various semi trailers and special vehicle related business, such as dump truck, tanker trailer, concrete mixer truck, and etc. Also, our business line ranges from the research, development, and design to the manufacture and sales for other automobile accessories, especially for axles and hydraulic cylinders. We're one of the earliest company to get the approval of the ISO, CCC and Compulsory Product Certification Enterprises. We have exported more than 30 countries from 2005.Looking forward to your visiting or calling.


We keep good relations with main truck manufactrers in China. And we can supply all brands dump truck made in China. HOWO, SHACMAN, BEIBEN, DONGFENG, SINOTRUK, BEIBEN, FOTON, C&C, and so on. More details for these trucks, feel free to contact us please.







We're expert for supply various Specialized Vehicle, such as sprinkler truck, wrecker truck, garbage truck,fire fighting truck, refuel truck, crane truck, Sewage Suction Truck, and so on. The followed is 5-10 cbm Sewage & Fecal Suction Truck specification:

Features
1. Adopt the Fonton designed mature dump truck chassis to install of Sewage tank, Vacuum pump, Four-way valve, Anti-overflow valve, Pipeline system and so on. The layout is reasonable and easy to operate.
2. High pumping efficiency, easy to operate, low fuel consumption, big power, low cost, one machine for Multi-purpose.

3. With self-absorption and self-discharging function, Pumping full time is less than 5 min, Suction length is more than 8m.
4. Sewage vacuum truck is mainly used for sucking septic tanks of neighbourhood, factory, school and household, it can also be used for cleaning the sewer sediments of city, dredging drains, watering, carrying water, green, fire fighting, drought fighting, one machine for Multi-purpose.

Notice Model: HTC5120GXWB
Chassis Model: CA1169
Front suspension/ Rear suspension (mm): 1100/2000, 1100/2050
Engine power(KW): 68/67
Number of axes: 2
Wheelbase: 4700, 4800
Tyre Specifications: 9.00-16, 10.00R20-16, 9.00R16
Fuel type: Diesel fuel.

Emission standards: GB17691-2005 Europe III, GB3847-2005
Exterior Size(mm) length*width* height: 6500, 6350*2080*2550
Tank Size (Tank length*longer axis*shorter axis): 3300*1700*1200
Suction depth: >8m
Load capatity: 10000
Engine: CA6dl-18
Engine manufacturers: FAW Xichai Machinery Co., Ltd.

Brand	FAW
Driving	4x2
Volume	8000-10000 liters
