- Model NO.：1035
- Capacity：1500kg
- Driving Type：4X2
- Steering：LHD, Rhd
- Brand：Sinohtc
- Transport Package：Container
- Specification：ISO
- Trademark：SINOHTC
- Origin：Shandong
- HS Code：87012000
- Production Capacity：100 PCS, Month
Dismensions |
| Overall length(mm) | 3935 |
| Overall width(mm) | 1415 |
| Overall height(mm) | 1835 |
| Cargo box length (mm) | 2480 |
| Cargo box width (mm) | 1325 |
| Cargo box height(mm) | 285 |
| Front/rear overhang(mm) | 795/940 |
| Wheel base(mm) | 2200 |
| Engine |
| Model | 3L16 |
| Type | 3-cyl. In line water cooled |
| Power(kw) | 22/3200 |
| Torque(Nm/rpm) | 73/2200 |
| Compression ratio | 18:1 |
| Cylinder bore/Piston(mm) | 80/90 |
| Displacement(L) | 1.357 |
| Standardment | Euro I |
| Suspension |
| Front suspension | Rigid housing axle leaf spring type | 5 pieces |
| Rear suspension | Rigid housing axle leaf spring type | 4 pieces |
| Transmission |
| Model | 5+1 synchromesh transmission |
| Type | Manual Mechanical |
| Speed ratio | I: | 4.605 |
| II: | 2.693 |
| III: | 1.645 |
| IV: | 1 |
| V: | 0.839 |
| R: | 3.816 |
| Steering |
| Type | Roller type |
| Clutch |
| Type | Single plate, dry type |
| Front brake System | Two section hydraulic drum |
| Rear brake System | Two section hydraulic drum |
| Tires |
| Type | 5.50-13/4 |
| Safe |
| Safe belt | Three-point belt |
| Other specifications |
| Chassis curb weight(kg) | 1020 |
| Load capacity(kg) | 1000 |
| Max GW(kg) | 2150 |
| Mini turning diameter(m) | 10 |
| Mini ground clearance(mm) | 180 |
| Max climbing ability | 25 |
| Max speed | 85 |
| Max Braking distance | 22 |
| Seat | 2 |
| Mini rate of Fuel consumption(L/100km ) | 5 |
Packaging & Shipping
40' HQ
Our Services
Spare parts, tech supporting
Company Information
Truck manufacturer
