• Model NO.：CLW
• Transmission Type：Manual
• Payload：10 Ton
• Fuel：Diesel
• Drive Wheel：4×2
• Engine Capacity：＜4L
• Condition：New
• Description：10 Wheeler 15000L-20000L Water Sprinkler Truck by
• Capacity：1000L,1100L,12000L,13000L,14000L,15000L,
• Material：Carbon Steel Dongfeng Water Sprinkler Tr
• Engine：160HP,190HP,210HP Dongfeng Water Tank Truck
• Tire：9.00r20, 9.00-20
• Top Manhole：API Standard, 500mm
• Driving Type：LHD or Rhd
• No.of Sleeper：with One Sleeper or Without Sleeper
• Driver Seat：Air-Supporting Driving Seat
• Brand：Dongfeng Road Wash Water Tank Truck
• Transport Package：Waxed Before on Board
• Specification：ISO, CCC, CE CE, ASME, ASTM, EEC, ASME, ASTM, EEC
• Trademark：CLW BRAND
• Origin：Hubei Suizhou
• HS Code：87053010
• Production Capacity：500unit,Month

DescriptionDONGFENG153 4X2 Water Spray TruckDrive Model4X2, LHD/RHDNo. of axles2ChassisEQ5140Fuel typeDieselVehicle Main DimensionsDimensions(L x W x H)mm8200×2480×3050Wheel base (mm)4500Overhang (front/rear) (mm)1250/2450Wheel track (front/rear) (mm)1940/1860Approach/Departure angle(°)22/16Weight in KGSCurb Weight6315 kgGVW.14490 kgMax. driving speed(km/h)90EngineModelB190 33Brand nameCumminsType4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-coolingHorse Power(HP)190HPEmission standardEuro IIIGearbox5 forwards & 1 reverseClutchReinforced diaphragm clutchSteering GearPower steering, hydraulic steering with power assistanceFuel tank of the engine (L)120Tire10.00-20 tire , 6 pieces including 1 spare tireBrakesDual circuit compressed air brakeTankMaterial Carbon steel Q235Tank Dimension5000*2000*1250mmDimension of the head protection part200×50×5mmSpraying area(mm)12000mm-16000mmVolume of the tank10-15CBMPumpSelf-priming pump, centrifugal pump for selectionDelivery time30 days after the paymentEquipment1.Equipped with front (rear,side)sprinkler, with rear working platform,Greening water cannon, 360°rotatable, adjust water to high or low(spray like columnar,vaporific ,drizzle);
2,Equipped with high power water pump:
Sprinkler width≥15m
Water cannon gunshot≥30m
Vertical suction≤6.5m
Flush pressure:250-450KPa
Time of drawing water :≥5minutes
Pump capacity:1000 L/minute;
