• Model NO.：CLW
• Payload：2-3 Ton
• Fuel：Diesel
• Drive Mode：6x4
• Maximum Horsepower：<200hp
• Condition：New
• Description：Concrete Mixer Truck with 8cbm, 9cbm, 10cbm Capaci
• Other Brand：Sinotruk Faw Shackman Beiben
• Dimension(L*W*H)：6850*2490*3180 Mm
• Engine Model：Yc4e140-20, 140HP
• Pump：Imported Brand, or Chinese Famous Brand
• Motor：Motor: Imported Brand, or Chinese Famous Brand
• Reducer：Imported Brand, or Chinese Famous Brand
• Mixer Truck Volume：3cbm, 4bm, 5cbm 8cbm Concrete Mixer Truck
• Export Markets：South America, Southeast Asia, Africa, Oceania, Mi
• Driving Type：LHD or Rhd
• Transport Package：Waxed Before on Board
• Specification：ISO, CCC, CE CE, ASME, ASTM, EEC, ASME, ASTM, EEC
• Trademark：CLW BRAND
• Origin：Hubei Suizhou
• HS Code：87053010
• Production Capacity：500unit,Month

DescriptionFORLAND 4X2 Concrete Mixer TruckDrive Model4X2ChassisBJ1143Vehicle Main DimensionsDimensions(L x W x H)mm6460*2255*3300Wheel base (mm)3600Overhang (front/rear) (mm)1230/1830Wheel track (front/rear) (mm)1774/1669Approach/Departure angle(°)24/20Weight in KGSGVW.13570Curb Weight5980Max. driving speed(km/h)85EngineModelYC4D130-33Type4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-coolingHorse Power(HP)130HPEmission standardEuro IIIGearbox5 forwards & 1 reverseClutchReinforced diaphragm clutchSteering GearPower steering, hydraulic steering with power assistanceFuel tank (L)150Tire8.25R20, 6 pieces+1 spare tireBrakesdual circuit compressed air brakeMixer DrumCapacity5CBMMax.Diameter1800mmMaterial16MnQ345Thickness5mmTilt11°-13°Feeding speed1 m³/minDischarging speed0.8 m³/minMaterial Remaining Ratio≤0.6%Driving systemSpeed reducerKy67-3-E(Germany brand)Hydraulic pump63 gear pump(Italy brand)Hydraulic motorGerotor motor(Italy brand)Heat device24V air-cooledOil hydraulic circuitClosed circuitWater supply systemTank volume62 LWater supply PatternsAir pressure Control SystemManipulartionFlexible shaft control    Drum Technique dataDrum Transmission Capacity3000 L4000 L5000 L6000 L7000 L8000 L9000 LDrum Capacity4700 L6000 L8000 L9770 L10447 L13400 L14900 LCharge Ratio0.670.670.640.630.670.6150.6Charging Speed≥3M3/ min≥3M3/ min≥3M3/ min≥3M3/ min≥3M3/ min≥3M3/ min≥3M3/ minDischarge Speed≥2M3/ min≥2M3/ min≥2M3/ min≥2M3/ min≥2M3/ min≥2M3/ min≥2M3/ minDischarge Residual Rate≤0.8 %≤0.8 %≤0.8 %≤0.8 %≤0.8 %≤0.8 %≤0.8 %Drum Rotation Speed0~16 r/min0~16 r/min0~16 r/min0~16 r/min0~16 r/min0~16 r/min0~16 r/minFilling Height1.92 M2.2 M2.3 M2.4 M2.5 M2.55 M2.6 MDischarging Minimum Height0.87 M1.13 M1.1 M1.13 M1.15 M1.2 M1.2 MAxes Angel14±0.514±0.514±0.514±0.514±0.514±0.512±0.5Overall Dimension3.9*1.8*24*1.95*2.24.8*2.3*2.155.2*2.1*2.44.4*2.1*2.475.2*2.2*2.65.4*2.3*2.65Oil Tank Capacity180 L180 L220 L260 L280 L280 L300 LNormal Working Temperature50~70ºC50~70ºC50ºC~70ºC50ºC~70ºC50ºC~70ºC50ºC~70ºC50ºC~70ºCMain parts parameter
Special Fuction Description of Cement Mixer Truckhydraulic systemadopting equipment imported from Italy,Germany,Japan, layout of system is simple,reliable transportation.water supply systemusing pressure water supply type, simplifying structure, saving power, reducing the weight of entire vehicle.mixing drumadopting plow structure, double helical surface blades, using different blade in different conic part, improved the quality of concrete, tank body with small angle of inclination in installing, reducing the height of center of gravity of the entire vehicle, good driving stability, moreover, smaller angle of inclination is more favorable for dry concrete discharge, reducing residual ratio.operation equipmentincluding flexible manipulator and connecting rod type manipulator, connecting rod type manipulator can realize multipoint manipulation.feeding/discharging devicefeed hopper, discharge chute can be rotated 180 degrees in the horizontal direction, so that it can adapt to different discharge position.tank body spray-painttank body surface sprays two-layer polyurethane paint, using stoving varnish technology, uniform coating, strong adhesion, luster is more durable.
   Our advantages:
a.Competitive Price and Excellent Quality,
b.More than 10 years' experience as a manufacturer
c.CCC,ISO,BV certification
d.Perfect after-sale service
e.Customized products available with us,
f.Export covering More than 50 countries and regions
g.Annual production value topped 1500,000,000 RMB (240,000,000 US d    ollars) per year


Our main products:
1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
Exporting

Chengli special automobile Co., Ltd is an automobile manufacturer , the company is a marketing enterprise of various heavy automobile brands, integrating international and domestic trade. Besides, the company has established a good relationship with domestic and overseas customers from Africa, South America, the Middle East and South Asia, winning a universal recognition and trust from the oversea customers and contributing to China trucks' entrance to the international market.
1.58 sets of military water trucks for national defense
2. Dump trucks in support of the United Nations
3. Fuel tank trucks exported to Sudan
4.78 sets of water truck exported to Nigeria
5. Dump trucks exported to the Ivory Coast, Kazakhstan
6.108sets of trucks exported to Libya
7.36 sets of dump trucks exported to North America
8.218 sets of garbage trucks exported to West Africa
9.60sets of water trucks exported to Congo
10. Garbage trucks exported to Vietnam
11.98 sets of dump trucks exported to Ghana

We are confident and committed to providing our customers with the best qualityand service all the time

If you are interested in our trucks, pls contact me, I will send our best quotation to you!
