Sinotruk Hydraulic Lift Aerial Platform Truck

QINGTE GROUP SPECIAL VEHICLES CO., LIMITED
  • Type：H
  • Certification：ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
  • Emission Standard：Euro 2, Euro 3, Euro 4
  • Hoesrpower：150-250hp
  • Payload：20T
  • Fuel：Diesel

Base Info

  • Model NO.：Hydraulic Lift Aerial Platform Truck
  • Transmission Type：Manual
  • Drive Wheel：4x2
  • Condition：New
  • Usage：Electric Maintaince
  • Color：Red, Yellow, Green, White, Blue.etc
  • After-Sale Service：One Year or 100000km Which Comes First
  • Transport Package：Nude Packing
  • Specification：Light duty truck
  • Trademark：SINOTURK
  • Origin：China
  • HS Code：8704224000
  • Production Capacity：3000 Units,Month

Description

EngineJE493ZLQ3A(ISUZU), Euro-2 emission, inter cooler, turbocharge, 102 HpGear box5S100, 5 forwards & 1 reverseTire9.00R20×7Cabin1880 mm Extended cabin, A/C, Radio FM with USBWheel base3360 mmBrakeDual circuit compressed air brakeAxle1058K1A(WP)/1062WP2(i=5.833)(2t/4.2t))SteeringPower steeringOthersExhaust brake, Clutch booster.
The folding arm aerial work truck , the working height is 12 meters;
the three-section folding arm has a maximum working radius of 5.8 meters and a maximum working height of 12 meters. 360 degree rotation.  Outrigger spanlongitudinal 2430mm, horizontal: front 1600MM, rear 2780MM. Hanging blue rated load≤ 200 kgHanging blue size1080×620×1100. The external tie rod is mechanically leveled, with the cylinder lock function, the rotary table and the hanging blue double position operation, the electronically controlled hydraulic up and down operation, the four legs all extend horizontally, and the four vertical legs are independent. Operation, the balance lever is all solid, with two toolboxes, stainless steel guardrail.
With insulation bucket(GFRP).
