• Model NO.：CLW
• Drive Mode：6x4
• Maximum Horsepower：200-300hp
• Condition：New
• Engine：290HP,336HP,350HP,375HP,380HP
• Cabin：1 Sleeper or Without Sleeper
• Mixer Body Volume：6cbm, 8cbm, 9cbm, 10cbm
• Hydraulics：Italy Brand or USA Brand
• Motor：Japanese Brand
• Drive Type：4X2,6X4,8X4
• Speed Reducer：Italy Brand
• Tire：12.00r20, 11r22.5, 315,80r22.5
• Tire Brand：Double Coin,Double Happiness
• Axle Brand：BPW,Fuwa
• Transport Package：Waxed Before on Board
• Specification：CCC, ISO9001
• Trademark：CLW
• Origin：Hubei Suizhou
• HS Code：8708706000
• Production Capacity：500 Unit,Month

Vehicle Parameterstruck chassisBEIBENCurb Weight (Kg)13785Payload (Kg)11000Overall Dimension(mm)9405×2500×3980Wheelbase (mm)3800+1450Front Overhang (mm)1515Rear Overhang (mm)2640Max   speed90km/hTire Specification12.00-20/12.00R20Engine ParametersModelWP10.290TypeDiesel 4-stoke Direct injection,6-cylinder in line, Turbo-charging, Inner cooling.Emission StandardEuro IIMax Power (KW)290HP(2200r/min)Max Torque1250 N.mMixing Drum ParametersGeometric Volume of Mixing Drum (m3)8-10Max Mixing Cubage (m3)8-10Feeding Speed (m3)≥2Discharging Speed (≥m3)≥1.0Leftover RateNearly ZeroMax Rotating Speed (r/min)14---16Mixing Drum Obliquity (°)13.5Max Mixing Drum Diameter (mm)φ2162Driving SystemSpeed ReducerItalian BONFILI-577LHydraulic PumpUS EATON5423-518Hydraulic MotorUS EATON5433-138RadiatorGerman AKG with Vacuum MeterWater Supply SystemWater Tank Capacity (CBM)2Water Supply ModeWater Pump; Pneumatic Pump
