• Model NO.：Shacman
• Drive Mode：6x4
• Maximum Horsepower：300-400hp
• Condition：New
• Engine：Wechai
• Gearbox：Fast (Fuller Technology)
• Tyre：12.00r20 Radial
• Color：Optional
• Main Parts：Top
• Transport Package：Nude Packing
• Specification：10m3
• Trademark：SHACMAN
• Origin：China(Mainland)
• HS Code：8701200000
• Production Capacity：20000 Sets,Year

Model10m3 concrete mixer truckPerformance & ParametersChassisSHACMANCurb Weight (Kg)8940Total Vehicle Weight  (Kg)25000Outline  Dimension(L*W*H)  (mm)8375*2495*3890Wheelbase  (mm)3625+1350Front Overhang  (mm)1525Rear Overhang  (mm)1775Max Traveling  speed77Vehicle  ConfigurationClutchDry  Single  Disc  Clutch  (φ 430)GearboxRTD-11509CDriving Type6*4Steering MechanismZF  technologyService BrakeDual-circuit  Air  BrakeParking BrakingSpring-powered  Air-cut-off  BrakeAuxiliary  BrakeEngine  Exhaust  BrakeTyre12.00R20Front  axle7.5T MANRear  axle13T MANEngine  ParametersModelWP10.340E22TypeDiesel 4-stoke Direct injection, 6-cylinder in line, Turbo-charging, Inner  cooling.Emission  Standard Euro IIMax Power336HPMax Torque1350  N. mMixing  Drum  ParametersGeometric Volume of Mixing Drum (m3) Max Mixing Cubage  (m3)10Feeding Speed (m3)≥ 3.5Discharging Speed (≥ m3)≥ 1.5Leftover RateNearly  ZeroMax Rotating Speed (r/min)14---16Mixing Drum Obliquity (° )13.5Max Mixing Drum Diameter  (mm)φ 2162Driving  SystemSpeed  ReducerItalian  TOP  6SPHydraulic  PumpTOP  089Hydraulic  MotorTOP  089RadiatorItalian  brand
