• Model NO.：ZZ1257N3847C
• Drive Mode：6x4
• Maximum Horsepower：>400hp
• Condition：New
• Brand：Sinotruk
• Axles：Three
• Drum：10m3
• Series：Concrete Mixer Truck
• Tire：12.00r20
• Transport Package：Nude
• Specification：CE, SGS and so on
• Trademark：Sinotruk
• Origin：Shandong, China
• HS Code：7706667658
• Production Capacity：5000PCS

ZZ1257N3847C, 6x4
Production Year2015, brand new truck,new condition
Cab
HW76 Extended cab,single berth,up-down,front-rear adjustable steering wheel,VDO instrument and control module,double-locking safety belt,outer sun shade,A/C

Engine
336HP WD615.69 Euro2
Engine type:Diesel 4-stroke direct injection engine,6-cylinder in-line with water cooling, turbo-charging & inter cooling
Displacement: 9.726 liters
Transmission
HW15710,10 forward gear and 2 reverse gear
Driving Axle
HC16,casting axle,rated payload of each axle:16tons
Front Axle
HF9  HOWO new off road 9T front axle,drum brake
Steering
ZF8098  hydraulic steering with power assistance
Tires
12.00-20  bias tire 10pcs,with one spare tire


Body
Drum Volume
9m3
Barrel Wall Thickness5mmMixing Blades thickness4mmLoading Speed (m3/min)≥  3.2Discharging Speed(m3/min)≥  2.2
Drum slope
13.5°
Drum Rotating Speed
0-16r/min
Discharged remain ratio
<0.5%



Performance
Max. speed (km/h):90
Curb. mass:13200kg
Total mass:25000kg
Wheel base (mm):3825+1350
Front/rear overhang (mm):1500/2240
Front/rear track (mm):2022/1830
Approach/ departure angle:16/24


Body configuration

Speed Reduction System
Brand Name
ZF
Model no.
P4300
Pump
Brand Name
Saao
Model no.
T90PV075
Motor
Brand Name
Saao
Model no.
T90MF75
Overall sizes (mm)
9050 (L) x 2490 (W) x 3800 (H)
