Sinotruck HOWO 9m3 Concrete Mixer Truck on Promotion
Qingdao Seize The Future Automobile Sales Co., Ltd.- Certification：ISO9000, CCC
- Transmission Type：Manual
- Emission Standard：Euro 2
- Displacement：8
- Payload：30T
- Fuel：Diesel
Base Info
- Model NO.：ZZ1257N3641
- Drive Mode：6x4
- Maximum Horsepower：300-400hp
- Condition：New
- Power：Diesel
- Truck Type：Concrete Mixer Truck
- Tire Design：Radial
- Seats：≤5
- Tire Certification：ISO
- Tire Type：Inner Tube
- Load Capacity：30t
- Type：Mixer Truck
- Transport Package：Nude Packing
- Specification：SGS, BV, ISO, CE
- Trademark：SINOTRUK HOWO
- Origin：Jinan, China
- HS Code：8704230090
- Production Capacity：1000 Units,Month
Description
Concrete mixer truck Chassis and tire Front axle: HF9 Front axle loading: 9000kg Rear axle: HC16 Rear axle loading: 16000kg Tires 12.00-20/12.00R20 Tire quantity: 11, with spare tire Drum specification Geometric volume of the drum 15 m³ Mixing Volume(effective capacity) 9m³ Gradient of the drum 13 Filling rate 60% Rest Rate ≤ 1‰ Rotational speed of the drum 0~14r/min Hydraulic Drive system Pump Model Italy ARK PV089 Max. Displacement 420bar/89cc/rev Motor Model Italy ARK MF089 Max. Displacement 420bar/89cc/rev Decelerator Model Italy TOP P68 Ratio 120.3 Water supply system Water Model Air pressure Volume of water tanker 440L
