• Model NO.：ZZ
• Fuel：Diesel
• Bearing Capacity：Medium
• Brand：HOWO
• Condition：New
• Function：Wrecker
• Driving Model：6*4 or 4*2or8*4
• Colour：Optional
• Logo：Optional
• Transport Package：Nude
• Specification：SGS
• Trademark：HOWO
• Origin：China
• HS Code：8701
• Production Capacity：2000

Basic Info.

Model NO. ZZ Fuel Diesel Bearing Capacity Medium Brand HOWO Condition New Function Wrecker Driving Model 6*4 or 4*2or8*4 Colour Optional Logo Optional Transport Package Nude Specification SGS Trademark HOWO Origin China HS Code 8701 Production Capacity 2000

Product Description

Heavy Duty Rotator Wrecker Towing Wrecker Truck



Integrated wheel and boom lift tow truck wrecker available in tandem or tri-axle configurations. Two or three stage boom.
From the gas-shock tool box doors to the standard complete wireless controls this wrecker will be the envy of every heavy driver. Keeping yourolling is our priority, so we've gone with all steel hydraulic linesand we've used only the best in cylinders, winches and steel. We've designed the INT to work in any environment and it will fill the gap in your fleet.


STANDARD FEATURES INCLUDE:
Steel body
Dual 40, 000lbs planetary winches
Manual spring tensioner
Two stage boom
Integrated underlift
Dual manual controls
Complete wireless controls
Dual rear spades with asphalt flipper feet
4 sets of frame forks
Frame fork adapters
Weather stripping on all tool boxes

OPTIONS AVAILABLE:
Hydraulic sidewinder legs with 20, 000lbs winches
Three stage boom
Low profile 144 euro lift
Custom toolbox configurations
In-cab controls
Rear tail board controls
Custom paint and graphics
Aluminum dress up kit
Additional frame forks
Custom attachments
Heavy duty wheel lift
Bus bars
Tri-axle body
Full installation services
Extended warranty

Manufacturer	Hubei Hua-Win Special Vehicle Manufacturing Co., Ltd
Chassis No.	ZZ1257N5847C (EUROII)
Chassis Manufacturer	Sinotruk
Engine No.	WD615.69
Engine Power (KW)	247
Oversize (L× W× H)	10645× 2496× 3250(3420)mm
Total Weight	19500/20400 Kg
Max Weight	32000 Kg
Axles	3
Drive	6x4
Wheelbase	5825+1350 mm
Tire Qty	10
Tire	12R22.5 12.00R20
Max lifting capacity-Optional	20000 Kg
Max lifting hight-Optional	5000/9600 mm
Lift-hoist telescope length-Optional	3530 mm
Winch rating pulling capacity	10000 Kg
Length of steel	40 m
Max under-hoist useful length	3100 mm
Rating under-hoisting capacity	12370/11470 Kg
Fully extended max under-hoisting capacity	7500/7000 Kg
Rating under-pulling capacity	50000 Kg
