• Model NO.：4x4 Off Road
• Certification：ISO9000, CCC
• Emission Standard：Euro 3
• Hoesrpower：120~140
• Payload：7t
• Fuel：Diesel
• Transmission Type：Manual
• Drive Wheel：4X4
• Condition：New
• Tire：7.50r16lt
• Cabin：Duolika
• Fuel Tank(L)：300L
• Drive：LHD , Rhd
• Work Lift Height：12m
• Boom Crane Loading Capacity：1000kg
• Wheelbase (mm)：3800
• Engine：120HP
• Transport Package：Nil
• Specification：OEM
• Trademark：Dongfeng
• Origin：China
• HS Code：8705909990
• Production Capacity：10000
• Package size per unit product：800.00cm * 250.00cm * 259.00cm
• Gross weight per unit product：6800.000kg

Overview Telescopic Bucket Truck (16 M)GeneralVehicle BrandDong Run ZeChassis BrandDongfengOverall Dimension7400 x 2300 x 3300 mmGVW / Kerb Weight5,810 kg / 5,485 kgCabCab Capacity2+3 persons allowedAir ConditionerAir conditioner is optionalEngineFuel TypeDieselEngine BrandDongfeng Chaoyang enginePower95 Ps (70 KW)Displacement3856 mlEmission StandardEuro IIIChassisDrive Type4X2,4x4 left hand drive or right hand driveTransmission5 - speed forward, 1 reverseWheelbase/No. of axle3300 mm / 2Tyre Specification6.50-16Tyre Number6 tyres and 1 spare tyreMax Speed95 km/hPaintMetallic paintSuperstructureCage Rated Capacity200 kgWorking Height16 mBeamThe beam is articulated & telescopic extension type, hydraulic actuated and controlledSlewingSlewing range is continuous 235° (minimum) with a slewing speed of maximum 15° per second.ControlControl both on the ground and remote control in cageSafety DeviceRelief valve, balance valve, double-way hydraulic lock, hand operated emergency hydraulic pumpLeveling SystemHydraulic stabilizer to level the vehicle on uneven groundOptionalInsulated cage; Wireless remote control system





Truck mounted aerial platform, which will be used to clean pole mounted solar panels for street lights. So it requires a special arrangement of truck mounted water tank as well as water hose at the basket.

The pole height is 6M so aerial lift should be 8-10M.
Water tank capacity can be 3000Ltr

Truck may be medium light truck of 3.% ton.
Welcome all around world customer visit our factory
