• Model NO.：9m3
• Drive Mode：6x4
• Maximum Horsepower：300-400hp
• Condition：New
• Geometric Volume：15.67m3
• Mixing Volume：9m3
• Maximum Diameter of Drum Body：2380mm
• Water Tank Capacity：450L
• Chassis Model：Zz1257n3847D1l
• Type of Driving：LHD
• Transport Package：Nude
• Specification：9510x2500x3970mm
• Trademark：Oriemac
• Origin：China
• Production Capacity：100unit,Month

TypeModelUnitG09ZZALPerformance of mixing drumGeometric volumem³15.67Mixing volumem³9Maximum diameter of drum bodymm2380Length of mixing drummm5101Angle of inclination °13.5Rotating speedr/min0~14Charge speedm³/min≥3Discharge speedm³/min≥2Residue ratio of discharge%<0.7Range of slumpcm5~21Hydraulic systemOil pump international brandMotor international brandReduction gears international brandHydraulic circuit Closed type Water supplywater tank capacity L450Way of water supply PnematicComplete machineBrand of chassis SinotrckChassis model ZZ1257N3847D1L(LNG)Type of driving Left-hand driveCurb weightkg14000maximum gross weightkg25000Driving type 6×4Wheel basemm3625+1350Tyre 12.00R20Means of power takeoff Power takeoff by flwheelNotice model XZJ5251GJBA1LExternal dimensions(length×width×height)mm9300×2500×3890EngineModel T10.34-40Rated powerKw/r/min250DisplacementL9.726Emission standard GB IV
