• Model NO.：LED Billboard
• Passenger Number：3
• Fuel Type：Diesel Oil
• LED Tube Core Type：IV
• Self-powered：Self-powered
• LED Screen Type：PH16
• Power Supply Mode：Own Generator-powered
• LED：Both Side or Single Side Optional
• Operating Environment：Temperature: -20c°~+60c°;
• LED Display Size：3.84m X2.24m X 2PCS
• Pitch/mm：P10 ~P16~P20~P25
• View Angle / °：110 H, 60 V
• Working Vlotage：110-220 VAC,+,- 10%
• Nput Signal：RF, S-Video, RGB, Rgbh, Yuv, Yc&Composition, etc
• Frame Frequency / Hz/S：60
• Refresh Rate Hz/S：600
• IP Rating：IP65
• Transport Package：Nil
• Specification：EDM
• Trademark：TIC
• Origin：China
• HS Code：8705909990
• Production Capacity：5000

Overview Outside body size (length × width × height mm)9600×2500×--Stage size (mm)Deep: 4880-7230; opening width: 9000-14780; height from ground: 1400Stage area (m2)64 square meters - 84 square metersStage step ladderAluminum pattern pedal + armrestStage supportThe stage legs are collected in the lower space of the stage frame, which can be directly screwed out and fixed.Extended connectionThe hinge is hinged to the main stage panel, manually flipped and becomes part of the stage, making operation quick and easyChassis legHydraulic legWing, main and sub stage, ceilingHydraulic expansionLeft backgroundHydraulic expansionChassis model
HFC1251P2K3D54S1VEmission StandardsGb17691-2005 country v, gb3847-2005Power (kw)179(240PS)Chassis configurationAir conditioning, airbag seat, vehicle tools, fire extinguisher, warning triangle, semi-high ceiling cabDisplacement6740mLTire11.00R20,12R22.5

Overall dimensions

(length × width × height mm)

11950×2500×3950(mm)



Total vehicle mass (kg)19500Loading mass (kg)2000Led screen (optional)The size is 8640*2880, and the screen folding is hydraulically expanded or closed (according to customer's optional)

BJ1049V8ADA-1BJ493ZLQ35995×2000×28602720*17604.82.56BJ1046V9JB5-H14A1-68C405130×1900×27502800*16004.62.56ZZ1047C3414D1454B2-95C405995×2025×29953840*17606.82.6BJ1043V9JEA-A4B2-95C405995×2025×29903840*17606.82.6HFC1041K7T4D25F5995×2030×29003840*17606.82.6BJ1049V9PD6-FEISF2.8s4129T5995×2000×28603520*17606.82.56BJ1049V9PD6-FECY4102-CE4F5995×2000×29003840*17606.82.56BJ1089VDPFG-SDYC4E140-317970×2190×37304800*224010.82.56

1.Stable capability for advertising truck led display
2.Super brightness waterproof shockproof led display
3.Good after-sales for Elnor mobile truck led display
4.True color reproduction for mobile advertising truck led display
5.Ultimate system reliability for vehicle/ trailer led display
6.Long life span and stable work
7.CE, RoHS, ISO9001 certification
8.9 years experience
9.Simple cabinet, easy to assemble, fast-set up

A) 17.2 sqm mobile advertising truck led display. 3.84m x 2.24m x2pcs.
B) Both side of the mobile truck are full color led displays.
C) The size of the waterproof cabinet is 960mm x1120mm, each weight 58kg/pcs.


Main features
1.Customized design
2.True color reproduction & authentic video quality
3.Ultimate system reliability
4.Fast set-up, easy service and full control
 LED display parameter


Elnor Outdoor Mobile/Truck Full Color LED Display/Billboard
Module
Pitch/mm
P10
P16
P20
P25
Module size/mm
160x160
128x256
320x160
200x200
Density of pixel/(dots/m2)
10,000
3,906
2,500
1,600
Pixel composition
1R1G1B
1R1G1B
1R1G1B
1R1G1B
Led encapsulation
DIP
DIP
DIP
DIP
Resolution of module
16X16
32X16
32X16
8X8
Main
Optimum viewing distance
≥10
≥15
≥17
≥23
View angle / °
110 H,60 V
110 H,60 V
110 H,60 V
110 H,60 V
Average power consumption/W/M2
300
300
350
400
Max power consumption/W/M2
750
600
850
650
Size of cabinet/mm
960X960
1024X768
1280X960
1000x1000
Resolution of cabinet
96X96
64x48
64X48
40X40
Weight of cabinet/kg
58
60
65
80
Driving method
1/4 scan constant current
Static constant current
Static constant current
Static constant current
Frame frequency / Hz/S
≥60
≥60
≥60
≥60
Refresh rate Hz/S
≥600
≥600
≥600
≥600
Luminance of white balance
≥7000 nits
≥6500 nits
≥6000 nits
≥5500 nits
Operation of Environmental Temperature/°C
below 30  to  above 50
IP rating
IP65
Working vlotage
110-220 VAC/+/- 10%
Grey scale/color
displaying colors≥16.7M(synchronized)
Brightness adjustment
256 levels of each color(manually),100 levels of each color(automatically)
Input signal
RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc
Control system
linsn(sending card,receiving cards and Hubs)
Average of non-failure life
>50,00h
Life span
>100,000h
Functionaless dot rate
<0.0001
 Certifications

Packaging & Shipping

Advantages
1.High brightness and be adjustable.Built-in functional card support brightness automatically adjustment.
2.A turn-key solution including professional sports software and hardware.
3.Rich advertising  LED display engineering experience both in domestic and oversea market.
4.Unbeatable product stability through strict quality control system.


Our service
1.Your inquiry related to our products or price will be replied in 24hrs
2.Protection of your sales area,ideas of design and all your private information
3.Top quality+reasonable price+responsible after service=successful & win


Trade terms
1. Payment:T/T,30% deposits before production,70% balance to be paid before dleiverying
2. Shipping freight are quoted under your requests
3. Shipping port:Shenzhen,mainland China
4. MOQ:1PC
