Beiben 1627 Vacuum Sewage Suction Tanker Truck 10000 L
Hubei Dong Runze Special Vehicle Equipment Co., Ltd.- After-sales Service:24
- Warranty:24
- Certification:ISO9000, CCC
- Emission Standard:E3-6
- Payload:10-12t
- Transmission Type:Manual
Base Info
- Model NO.:DRZ5160GXWND
- Fuel:Diesel
- Tank Volume:6000~10000L
- Drive Wheel:4x2
- Hoesrpower:251-350hp
- Condition:New
- Tire:12.00-20, 12.00r20, 12.00r24, 14.00-20
- Alxes:Mercedes Benz Technology
- Engine:Weichai, Hino
- Steering System:Zf8098, Tas85
- Transimission:6~9-Speed, Single, Dry
- Emission Standards:Euro 2, Euro 3, Euro 4
- Tank Capacity:6000~10000L
- Driving Type:LHD ,Rhd Optional
- Transport Package:Nil
- Specification:Customizing
- Trademark:BEIBEN TRUCK
- Origin:China
- HS Code:8705909990
- Production Capacity:10000
Description
Overview
TIC5160GXW beiben Vacuum Sewage Suction TruckDimension(Length*width*height) (mm) 8150×2500×3050 Chassis ND1624 Track(front/rear) (mm) 1995/1800 Approaching angle//Departure angle() 23/15 Suspension(front/rear) (mm) 1410/2200 Min distance to the ground(mm) 399 Wheel distance(front/rear) (mm) 4500 GVW (KG) 19000 Kerb weight (kg) 7500 Rated loadkg 10000 Configuration 4*2 Tank Volume (m³) 10 Design volume 10000 L 10 Main body material Q235A/6MM Vacuum pumps model 50QZDG-45/400 Maximum AOB ° ≥45° Effective suctionm ≥ 5 Vacuum systemMPa ≥11 Lifting times ≤45 Cover opening Angle° ≥75° Cover open time (s)s ≤25 Suction pipe diameter (mm)(mm) 100 Tanks full sucked time (min) ≤12 4*2/4x4ND1160A41 4100 WP6.180 ND1163A48J 4800 WP10.270
WP10.290 4*4 ND2161E48 4800 WP10.270 ND2162E48J WP10.300N ND21600E41J 4500 WP10.336
Model
ND2160E48J (4*4)
Engine
290 HP EURO II-V
chassis
BeiBen 4x4 AWD chassis
Outside dimension(mm)
8826×2500×3355
volume of tank
6000L~ 10000L
Material of tank
Carbon steel
Thickness
6mm
Total mass (kg)
16000
Kerb mass (kg)
7960
Rated payload(kg)
7910
Wheelbase (mm)
4800
Tread(front/rear)
1995/1800
Approach/departure angle
30/28
Front /rear suspension
1410/2616
Minimum turning diameter
20.4
Clutch type
GFX420, diaphragm spring clutch
Gear box type
9JS119,mechanical , 9 forwards, manual
Tire type
14.00R20 (6+1)
Fuel tank capacity (L)
300
Max.gradient
60
Max. Speed(Km/h)
85
Battery(V)
Electrical system storage battery 2X12V/135Ah
generator
28V-35A
Starter
5.4Kw/24V
A/C
YES
Chassis
Model
ND11601A48J
Traction type
4X2
Driving type
LHD
Driver's cab
Long cabin, A/C
Dimensions in (mm)
Wheel base(mm): 4800
Overall size(mm): 8690x2500x3080
Engine
Maker: WEICHAI
Diesel 4 stroke direct injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & intercooling
Engine model: WP10.270E31
Emission Standard: EUROIII EGR
Maximum output: 270HP /1900 rpm
Number of cylinder:6
Displacement: 9.726L
Clutch
430mm, hydraulically operating with air assistance
Transmission
Fuller 9JS135
Steering
TAS85
Front Axle
Benz front axle 7.5 ton
Rear Axle
Benz strengthened type 13T, double reduction drive axle
Ratio: 5.263
Spring
10/8+6
Types
12.00-20 Bias tyre
No. of tyre
6+1(spare)
Fuel tank
400L Aluminium
PTO
QH50
Electrics
Operating voltage: 24V, negative grounded
Kerb weight(kg)
6920
Body
Tank Volume
8m3,9m3,10m3,12m3 CertificationsPackaging & ShippingFAQ
2 .Can I have samples of this type of product to test the quality?
Yes, you can buy any sample to test the quality,our MOQ is 1 unit.
3. What's the delivery time and can you lower the price?
It depends on your order.The delivery time is within 30 workdays after we received your prepayment. If you have placed an order of large quantities, then,of course, the price can be lowered.
4.Can you supply some quick-wear parts? Yes, we can supply the parts as your request,such as traction,traction pin,balance beam and plate spring,hanging accessories,turntable,all kinds of brake pads,brake pan, bearings,etc.
6.Do you have any used products for sale? We have products in stock for choices,the prices are favorable,we'll show you our stock products if you need.
7.What's the payment terms?TT 30% as deposit, balance before shipment by TT or at sight.
8. How to guarantee customers get the goods smoothly after they payment?
Don't worry,dear.We have joined the trade assurance,you can place the order by trade assurance,if we don't delivery products, the deposit will be returned to you.
9.How can you ensure the quality of the products?
WP10.290
Model
ND2160E48J (4*4)
Engine
290 HP EURO II-V
chassis
BeiBen 4x4 AWD chassis
Outside dimension(mm)
8826×2500×3355
volume of tank
6000L~ 10000L
Material of tank
Carbon steel
Thickness
6mm
Total mass (kg)
16000
Kerb mass (kg)
7960
Rated payload(kg)
7910
Wheelbase (mm)
4800
Tread(front/rear)
1995/1800
Approach/departure angle
30/28
Front /rear suspension
1410/2616
Minimum turning diameter
20.4
Clutch type
GFX420, diaphragm spring clutch
Gear box type
9JS119,mechanical , 9 forwards, manual
Tire type
14.00R20 (6+1)
Fuel tank capacity (L)
300
Max.gradient
60
Max. Speed(Km/h)
85
Battery(V)
Electrical system storage battery 2X12V/135Ah
generator
28V-35A
Starter
5.4Kw/24V
A/C
YES
Chassis
Model
ND11601A48J
Traction type
4X2
Driving type
LHD
Driver's cab
Long cabin, A/C
Dimensions in (mm)
Wheel base(mm): 4800
Overall size(mm): 8690x2500x3080
Engine
Maker: WEICHAI
Diesel 4 stroke direct injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & intercooling
Engine model: WP10.270E31
Emission Standard: EUROIII EGR
Maximum output: 270HP /1900 rpm
Number of cylinder:6
Displacement: 9.726L
Clutch
430mm, hydraulically operating with air assistance
Transmission
Fuller 9JS135
Steering
TAS85
Front Axle
Benz front axle 7.5 ton
Rear Axle
Benz strengthened type 13T, double reduction drive axle
Ratio: 5.263
Spring
10/8+6
Types
12.00-20 Bias tyre
No. of tyre
6+1(spare)
Fuel tank
400L Aluminium
PTO
QH50
Electrics
Operating voltage: 24V, negative grounded
Kerb weight(kg)
6920
Body
Tank Volume
8m3,9m3,10m3,12m3
1.Are you trading company or manufacturer ?
We are Group Corporation manufacturer ,have Group Factories Contractor.2 .Can I have samples of this type of product to test the quality?
Yes, you can buy any sample to test the quality,our MOQ is 1 unit.
3. What's the delivery time and can you lower the price?
It depends on your order.The delivery time is within 30 workdays after we received your prepayment. If you have placed an order of large quantities, then,of course, the price can be lowered.
4.Can you supply some quick-wear parts? Yes, we can supply the parts as your request,such as traction,traction pin,balance beam and plate spring,hanging accessories,turntable,all kinds of brake pads,brake pan, bearings,etc.
6.Do you have any used products for sale? We have products in stock for choices,the prices are favorable,we'll show you our stock products if you need.
7.What's the payment terms?TT 30% as deposit, balance before shipment by TT or at sight.
8. How to guarantee customers get the goods smoothly after they payment?
Don't worry,dear.We have joined the trade assurance,you can place the order by trade assurance,if we don't delivery products, the deposit will be returned to you.
9.How can you ensure the quality of the products?
Don't worry,dear.We have joined the trade assurance,if the products have quality problems when you received them,the payments can be refund to you.
