• Model NO.：Aerial Work Platform Truck
• Payload：200
• Fuel：Diesel
• Transmission Type：Manual
• Drive Wheel：6x4
• Condition：New
• Tire：7.00r16
• Cabin：I.S.U
• Fuel Tank(L)：200L
• Drive：LHD
• Work Lift Height：12-18m
• Boom Crane Loading Capacity：1000kg
• Wheelbase (mm)：3360 mm
• Engine：130HP
• Transport Package：Nil
• Specification：18m, 20m, 24m 22m
• Trademark：DRZ
• Origin：China
• HS Code：8705909990
• Production Capacity：10000

Vehicle ParametersGeneralVehicle ModelDRZ5040JGK12QVehicle Brand DRZChassis BrandQing ling IS UOverall Dimension(mm)5998×2000×2960GVW/Curb Weight(kg)4495 /4170Chassis ParametersCabCab Seat2Air ConditionerOptionalEngineFuel TypedieselEngie Model4KH1CN5LSEngine BrandQing lingPower72hpDisplacement(cc)2999Emmission StandardEuro 5-6ChassisDrive Type4*2Transmission5 speed, ManualWheelbase(mm)3360Tyre Specification6.50-16Tyre No.(pcs)6+1Max Speed(km/h)99PaintYellowAerial platform structure parametersworking height(m)12Maximum working radius(m)6Arm Materialcarbon steel Q345Arm Thickness Working height at Max.working radius(m)6.4Working radius at Max.working height(m) Outrigger distance(mm)2880*3560Platform average rise speed(m/s)≤0.4Platform average fall speed(m/s)≤0.4Rotation speed (1r/min)1Arm structure typeThree sectionOutrigger stretch time (s)40Rotation360°continuous rotaryOutriggerH type,independentlyRemarks1. truck chassis brand is selectable 2.The outrigger operation box is equipped with a lighting device to facilitate work at night and configure the vehicle's bidirectional level to ensure the vehicle's level and ensure safety.3.The boom rotation is designed as a one-piece swivel to avoid assembly gaps during reassembly in production, and increases the space of the platform.4.Front and rear H-shaped legs, good stability, can be operated simultaneously or individually, standard washing boxes for all models 5.Upper arm limit device, when the upper arm exceeds the safety angle, the boom will be in a self-locking state to ensure the safety of the operator 6.Up and down steps are equipped on the side(aluminum alloy platform optional )7.The thickened cylinder seat and the boom cylinder block are all specially thickened to ensure the stability of the boom 8.Sectional coating to ensure the paint quality of the vehicle 9.All cutting parts are CNC laser cutting



 FTR IS U Telescopic Boom Aerial Working Truck 23m Working Height:



Specification of QL High Altitude Operation Truck 14-16mItemSpecificationItemSpecificationGeneralTruck NameQL High Altitude Operation Truck Overall Dimension (mm)6880x1980x3100Truck ModelQL1070A5HWYWheel Base (mm)3360

Traction System

4 x 2Gross Weight (kg)6080Cab Capacity1+1+3Curb Weight (kg)5755TransmissionmanualFront Wheel Tread (mm)1504Chassis BrandQLRear Wheel Tread (mm)1425Tyre Model7.00-16 14PR;
7.00R16 14PRApproach Angle (°)24Quantity of Tyre6Departure Angle (°)16Quantity of Axles2Front Overhang (mm)1015Max Speed (km/h)110Rear Overhang (mm)2155ChassisChassis Model QL1070A5HWYLeaf Spring8/6+5Engine (Motor)BrandQLType of FuelDieselModel4KH1CN5HSDisplacement (ml)2999Power (kw)96Emission StandardEuro  5-6EquipmentsMax Operation Height (m)14-16Arm Rotation Angle 360°Max Operation Radius (m)7.2 (360°)Arm Rotating Speed (r/min)0-2Operation Stage Dimension (mm)1100x570x1000Support Legs4 H-shap legs(2 front & 2 rear)Operation Stage Rating Loading Weight (kg)200Operation Control SystemElectrically hydraulic controlHook Loading Weight (kg)≥1000Type of Working Arm3 section arms

NOTE:

1. Any part can be customized depending on customers' demand.

2. 12 months whole vehicle warranty

3. We could support you original spare parts. Besides, we can give assistance in the following days by email or telephone. If necessary, our outwork engineer could go for technical assistance.



ISU mounted Crane truck ( 3.2Ton boom crane SQ3SK2Q)

General

Vehicle Brand

 DONG RUN ZE TRUCKS

Chassis Brand

I.S.U .U

Overall Dimension

6500 * 2100 * 3100 mm

GVW / Kerb Weight

7,300kg / 4,000kg

Cab

Cab Capacity

2 persons allowed

Air Conditioner

Heating/cooling air conditioner

Engine

Fuel Type

Diesel

Engine Brand

I. . Z.U

Power

130 HP (88 KW)  4KH1

Displacement

2999 ml

Emission Standard

Euro 4 or 5

Chassis

Drive Type

4X2, (Left hand drive ONLY)

Transmission

Manual MSB 5 speed levers with 1 reverse

Wheelbase/No. of axle

3360 mm / 2

Tire Specification

7.00-16

Tire Number

6 tires and 1 spare tire

Max Speed

90 km/h

Paint

Metallic paint

Superstructure

Cargo Box Dimension

4000*1900*500 mm

Crane Type

Telescpoic boom crane

Max Lifting Capacity

3200 kg

Slewing Angle

360° All rotation

Crane Weight

1229kg

Installation Space

850 mm

Control panel

English or Your language

All standard accessories: Basic tool kit, English manual...

Optional

** Knuckle boom crane.

** Hydraulic tipper box.

** Box thickness according to requirement.

** Box height could be nominated
** Remote Control Box optional





ItemsParameterTruck Model5070JSQ2Crane Parameter  Max Lifting Capacity3200 kgMax Lifting Moment6.8 T.MRecommend Power14 kwMax Oil Flow of Hydraulic System25 L/minMax Pressure of Hydraulic System20 MpaOil Tank Weight30 LCrane Weight1229 kgInstallation Space850 mmRotation Angle360° All Rotation  Cargo Body  ThicknessSide2mmFloor3mm



Similar Key Words: hydraulic boomlifter, overhead working truck, truck mounted aerial platform, aerial beam lifter, man lift truck, articulated basket platform, skylift, insulated aerial cage truck

tictrucks.en.made-in-china.com

PACKING & DELIVERY

Aerial platform truck 16m water tank and water pump ,Truck Mounted Aerial Work Platform water tank,Work Platform water tank truck,aerial bucket truck  water tank,bucket truck with water tank ,Truck Mounted water tank Aerial Work Platform



Truck mounted aerial platform, which will be used to clean pole mounted solar panels for street lights. So it requires a special arrangement of truck mounted water tank as well as water hose at the basket.
