• Model NO.：HOWO Fire Pumper
• Transmission Type：Manual
• Payload：30T
• Fuel：Diesel
• Drive Wheel：8X4
• Horsepower：351-450hp
• Condition：New
• Tire：12.5r20 Radial off Road Tire
• Engine：380HP -440HP
• Emission Standards：Euro 2, Euro 3, Euro 5-6
• Water Tank Capacity：28000liters
• Transport Package：Nil
• Specification：mili tary standard.
• Trademark：HOWO
• Origin：China
• HS Code：8705309000
• Production Capacity：10000

Dimension(Lx W xH)(unloaded)(mm)9895×2496×2958Tank Volume (mm)

20cbm

tank body(thickness):5mm ,material: carbon steel; sprinkling equipment both in front and in rear; special anti-corrosion treatment

Approaching angle/Departure angle(°)13.5/11.5Overhang(front/rear) (mm)1500/2445Wheel base (mm4300+1350Max speed(km/h)90Curb weight(kg)12450Loading Weight(kg)12400

Engine

(Steyr technology, made in China)

ModelWD615.69,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and intercooling, directly injection Fuel typeDiesel Power, max(kw/rpm)247/2200 EmissionEUROFuel tanker capacity300TransmissionModelHW19710

Brake system



Service brakeDual circuit compressed air brake Parking brakespring energy, compressed air operating on rear wheels

Steering system



  Front axleHF9Rear axleHC16Tyre12.00R20

Electrical system



Battery2X12V/165Ah Alternator28V-1500kw Starter7.5Kw/24VCabHOWO76 cab, all-steel forward control,55ºhydraulically tillable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers



Product nameHowo 8*4 fire fighting truckTank capacity21.2m3Tank size(mm)8350*2420*1250Cab seat2 Gross weight(kg)40000Curb weight(kg)18350Dimension(mm)11850*2500*3660Max speed(km/h)95Axle load(kg)8000/8000/27000Front/ back track(mm)2022/2022,1830/1830Front/ back suspension(mm)1500/2600Wheelbase(mm)1800+4600+1350Tire NO12Tire spec12.00-20,12.00R20Engine modelD12.42-40Displacment(ml)11596Power(kw)309Horse power(hp)420







1.





Fire fighting water tank lorry truck 28000L
