• Model NO.：Oilfiled Vacuum Tanker
• Fuel：Diesel
• Tank Volume：14, 000 Liters-18, 000liters
• Drive Wheel：6x4
• Hoesrpower：210-290HP
• Condition：New
• Drive Type：LHD,Rhd
• Dimension(L*W*H)(mm)：9600*2500*3690mm
• Tyre & Spare Tyre Spec：10.00-20, 10.00r20, 11.00-20, 11.00r20
• Gvw./Kerb Wt.：25000,13000(Kg)
• Wheelbase (mm)：4350+1300
• Tank Material：Q235 Carbon Steel Optional Lined PE
• Clean Water Tank Capacity：0 Litres
• Sewer Water Tank Capacity：14000 Litres -18000L
• High Pressure Pump：Optional 16MPa, 18MPa
• Vacuum Pump：Optional Water Ring Pump
• Transport Package：Nil
• Specification：Vac Tanker
• Trademark：Dong Run Ze
• Origin：China
• HS Code：8705999090
• Production Capacity：80000

Main specification

Product model and name

DRZ 5250GXWE4 sewage sucking truck

Gross weight(Kg)

24900

Drive type

6X4

Curb weight(Kg)

11705

Overall dimension(mm)

9600X2480X3550

Approach/departure angle(°)

32/16

Cab seats

3

Axle No.

2

Front/rear hang(mm)

1250/2700

Axle load(Kg)

7000/17900

Wheelbase(mm)

4350+1300

Max speed(Km/h)

85





Chassis specification

Chassis model

EQ1250

Manufacturer

Dongfeng Motor Co., Ltd

Brand name

Dongfeng

Dimension(mm)

9570×2470×2850

Tyre specification

10.00-20

Tire No.

10+1(one spare)

Steel spring number

9/10

Front track base(mm)

1960

Fuel type

Diesel

Rear track base(mm)

1860/1860

Emission standard

Euro 3

Transmission

9 forward gear

Cab

One and half row,3 person allowed with A/C and power-assisted steering

Engine model

Engine manufacturer

Displacement(ml)

Power(Kw)

YC6A240

Guangxi Yuchai Engine Co.,Ltd

7255

177(240HP)

Tank body

Tank capacity(m³)

18

Tank material

QB235 Carbon steel

Main CharacteristicThe truck is equipped with high-powered vacuum suction pump and high quality hydraulic system. With rear lid of the tank opened hydraulically, and double cylinders on both sides of the tank lifting up, the truck can dump the sewage directly through the rear lid out of the tank. Characterized by high vacuum, large capacity, high efficiency and good seal, the truck is widely used. Full tank pumping time:≤ 5min; suction width:≥ 8m.Very suitable for sucking sewer sediments, such as mud, silt, stones, bricks and other big objects.



18000 liters Sewage suction truckVehicle nameSewage suction truckChassis modelsEQ1258GSZ5DJvehicle size(mm)9400*2500*3700Wheelbase4350+1300Hopper Volume18000litersTotal mass(kg)25000Rated Mass(kg)11800kerb mass(kg)13005Tire size295/80R22.5 18PRTire numbers10+1Engine typeYC6JA240-50Engine power240HPFuel typedieselEmission standardsEuro3,4,5Gearbox8 forward gears and 1 back gearsTop speed90Chassis configuration9ton rear axle,ABS,air conditionerReconfigurationWith view dung window, 1 flow port, hand washing device, 1 suction pipe, vacuum pump, oil and water separator, self-discharging function, back door hydraulic openingLooking forward to receiving your inquiry!
