Dongfeng Aerial Platform Working Truck with Water Sprinkler Water Tank Volume 4000 L
Hubei Dong Runze Special Vehicle Equipment Co., Ltd.- Warranty:24
- Type:H
Base Info
- Model NO.:OEM
- Certification:ISO9000, CCC
- Emission Standard:Euro 3
- Hoesrpower:150-250hp
- Payload:16t
- Fuel:Diesel
- Transmission Type:Manual
- Drive Wheel:4x2
- Condition:New
- Tire:10.00-20, 9.00-20
- Cabin:Duolika
- Fuel Tank(L):300L
- Drive:LHD , Rhd
- Water:4000L
- Work Lift Height:14m, 16m, 18m, 20m, 22m
- Boom Crane Loading Capacity:1000kg
- Wheelbase (mm):3950, 4500, 5200
- Engine:160HP, 170HP, 190HP
- Transport Package:Nil
- Specification:OEM
- Trademark:Dongfeng
- Origin:China
- HS Code:8705909990
- Production Capacity:10000
- Package size per unit product:880.00cm * 255.00cm * 340.00cm
- Gross weight per unit product:6800.000kg
Description
Technical parameters
Total Mass(kg)
12450
Curb Weight(kg)
5855
Rated qualityof(kg)
6400
Chassis Model
EQ1121
Approach/Departure Angle
21/14(°)
Front/Rear Overhang
1250/2150
Dimensions(mm)
7350x2480x2950
Number of spring
8/10+8
Number of axes
2
Maximum speed
85
Tire Specifications
10.00-20 ,9.00-20
Number of tires
6
Front track
1900
Rear track
1800
Wheelbase
3950
Axle load
4370/7720
Emission Standards
Euro3
Type of fuel
Diesel
Engine parameters
Engine Model
B190-33
Engine Manufacturer
Dongfeng Cummins Engine Co., Ltd
Engine Displacement(ml)
5900
Engine power(kw)
140
Chassis
Description
1. Dongfeng 4x2 chassis, flat cab with sleeper, left/right hand drive with A/C;
2. Dongfeng 6 cylinder 190HP diesel engine, 6 speed gear box, 10.00-20 tire;
3. Power steering, air brake.
Modified
Description
1. Tank effective volume:6000L -8000L, made by 4-6mm carbon steel plate or corrosion resistant plate;
2. Equipped with front (rear,side)sprinkler, with rear working platform,Greening water cannon, 360°rotatable, adjust water to high or low(spray like columnar,vaporific,drizzle);
3. Pump parameters:model:65QZ40/50N(S),flow:660L/min,lift:50m,input shaft speed:1450r/min,shaft power:9.25KW,vertical suction:6.5m,direction of input shaft:left-right rotating;
Pump parameters:model: 80QZ60/90N(S),flow:1000L/min,lift:50m,input shaft speed:1180r/min,shaft power:22.5KW,vertical suction:6.5m,direction of input shaft:left-right rotating
4. Equipped with self-flow valve,fire hydrant interface,self-priming and self-draining pump,inhale to tanker directly and inject by fire hydrant.
Component
Basic composition:chassis,tanker,PTO,transmission shaft,special self-priming pump,pipeline,jet,rear work platform.Optional equipment:GPS, gimbaled nozzle,VVB,pneumatic valve,visual operating system,external power,medicament tray.
Application
Our company develop all kinds of watering trucks, mainly used in city roads,big factory,troops,parks,cleaning,proventing dust,watering,crop-dusting and so on.We can produce different all kinds of watering trucks according to customer's requirements.
Product advantage
reasonable price,multiple functions,easy operation
Description
Technical parameters
Total Mass(kg)
12450
Curb Weight(kg)
5855
Rated qualityof(kg)
6400
Chassis Model
EQ1121
Approach/Departure Angle
21/14(°)
Front/Rear Overhang
1250/2150
Dimensions(mm)
7350x2480x2950
Number of spring
8/10+8
Number of axes
2
Maximum speed
85
Tire Specifications
10.00-20 ,9.00-20
Number of tires
6
Front track
1900
Rear track
1800
Wheelbase
3950
Axle load
4370/7720
Emission Standards
Euro3
Type of fuel
Diesel
Engine parameters
Engine Model
B190-33
Engine Manufacturer
Dongfeng Cummins Engine Co., Ltd
Engine Displacement(ml)
5900
Engine power(kw)
140
Chassis
Description
1. Dongfeng 4x2 chassis, flat cab with sleeper, left/right hand drive with A/C;
2. Dongfeng 6 cylinder 190HP diesel engine, 6 speed gear box, 10.00-20 tire;
3. Power steering, air brake.
Modified
Description
1. Tank effective volume:12000L, made by 4-6mm carbon steel plate or corrosion resistant plate;
2. Equipped with front (rear,side)sprinkler, with rear working platform,Greening water cannon, 360°rotatable, adjust water to high or low(spray like columnar,vaporific,drizzle);
3. Pump parameters:model:65QZ40/50N(S),flow:660L/min,lift:50m,input shaft speed:1450r/min,shaft power:9.25KW,vertical suction:6.5m,direction of input shaft:left-right rotating;
Pump parameters:model: 80QZ60/90N(S),flow:1000L/min,lift:50m,input shaft speed:1180r/min,shaft power:22.5KW,vertical suction:6.5m,direction of input shaft:left-right rotating
4. Equipped with self-flow valve,fire hydrant interface,self-priming and self-draining pump,inhale to tanker directly and inject by fire hydrant.
Component
Basic composition:chassis,tanker,PTO,transmission shaft,special self-priming pump,pipeline,jet,rear work platform.Optional equipment:GPS, gimbaled nozzle,VVB,pneumatic valve,visual operating system,external power,medicament tray.
Application
Our company develop all kinds of watering trucks, mainly used in city roads,big factory,troops,parks,cleaning,proventing dust,watering,crop-dusting and so on.We can produce different all kinds of watering trucks according to customer's requirements.
Product advantage
reasonable price,multiple functions,easy operation
Aerial platform truck 16m water tank and water pump ,Truck Mounted Aerial Work Platform water tank,Work Platform water tank truck,aerial bucket truck water tank,bucket truck with water tank ,Truck Mounted water tank Aerial Work Platform
Work Platform
Truck mounted aerial platform, which will be used to clean pole mounted solar panels for street lights. So it requires a special arrangement of truck mounted water tank as well as water hose at the basket.
The pole height is 6M so aerial lift should be 8-10M.
Water tank capacity can be 3000Ltr
Truck may be medium light truck of 3.% ton.
