• Model NO.：High Pressure Jetting Combined Sewer Truck
• Drive Wheel：4x2
• Hoesrpower：100-190HP
• Condition：New
• Drive Type：LHD,Rhd
• Dimension(L*W*H)(mm)：6200*2030*2650 mm
• Tyre & Spare Tyre Spec：7.00r16
• Gvw./Kerb Wt.：7360, 4930 Kg
• Wheelbase (mm)：3300 mm, 3360 mm, 3800 mm
• Tank Material：Q235 Carbon Steel Optional Lined PE
• Clean Water Tank Capacity：1000 Litres
• Sewer Water Tank Capacity：3000 Litres
• High Pressure Pump：16MPa, Flow Rate 130L,Min
• Vacuum Pump：Water Ring Pump Sk-6
• Transport Package：Nil
• Specification：Vacuum Tank Combined Sewer Jetting Truck
• Trademark：Dongfeng
• Origin：China
• HS Code：8705999090
• Production Capacity：80000

General

Truck Name

Sewage suction truck

Drive Type

4x2, left hand drive,right hand drive is optional

Gross Vehicle Weight(kg)

9400

Curb Weight (kg)

4605

Overall Dimensions L*W*H(mm)

6450×2285×2700

Engine

Engine Model

CY4102-E3C

Engine Brand

CHAOCHAI

Fuel Type

Diesel

Power

91kw/120HP

Emission Standard

Euro III

Displacement(ml)

3856

Engine Type

4 cylinders in line,water cooling, turbo-charged diesel engine,inter-cooling

Chassis

Chassis Brand

Dongfeng

Front/Rear Axle Load(KG)

3885/5515

Tire No.

6

Tire Specification

7.50-16 Nylon tire

Wheelbase (mm)

3800

Axle No.

2

Gear Box

5 speed forward with 1 reverse, manual

Brake

Air brake

Air Conditional

Suitable for tropical climate

Front/rear suspension(mm)

1180/1715

Leaf Spring No.

11/9+7

Sucking System

Tank Volume(L)

5000

Tank shape

Cylindrical

Tank Material

4mm thick carbon steel

Vacuum Pump

Weiyi pump(Weilong is optional)

Suction Depth(m)

More than 6 meter

Tank Tipping angle(°)

More than 45

Rear door

Open and closed by hydraulic cylinders





Basic equipment of sludge tank truck

Imported vacuum pump, power-take-off, hydraulic cylinders, control valves , pressure gauge,

 water gas separator , oil water separator, level inspection window, suction hose,pipeline system,etc.

1.Tank can be lifted hydraulically to 40 to 45 degree.Rear door can be opened&closed

 hydraulically. With full opening design, discharge can be very quick&complete.



2.Overfill system with music horn is equipped to prevent the vacuum pump damage from sewage water into vacuum pump when the tank is full.



3.Super power of vacuum pump, seamless die casted sheel cover, designing for container  with high ability of pressure-resistance,double hydraulic jack system, morestrength then cesspit

emptier.

  brand new high pressure vacuum suction truck



Dongfeng 4*2 combined sewer jetting truck

#

Descriptions

Specifications and types

General

Truck Brand

 Dong Run Ze



Chassis Brand

Dongfeng



Approx. Dimension

6200*2030*2650  mm



GVW./Kerb Wt.

7360/ 4930 kg

Cab

Cab Capacity

3 persons' seat



Air Conditioner

Air Conditioner is optional

Chassis

Drive Type

4X2,right hand drive or left hand drive



Fuel Type

Diesel



Engine Make & Model

Chaochai engine



Power

120HP



Displacement

3760 ml



Emission Standard

Euro 2



Wheelbase/No.of axle

3360 mm / 2



Tyre Specfication

                  7.00R16



Tyre Number

6 tyres and 1 spare tyre



Axles weight

Front axle 2.4 ton rear axle 4.2 ton



Transmission

WLY6T46  6 forwards 1 reverse



Max Speed

80 km/h



Paint

Automative metallic paint

Upper part

Clean water Tank Capacity

2500 Litres



Sewer water tank capacity

5500 litres



High pressure pump

High pressure pump pressure 16mpa, flow rate 130L/min



Vacuum pump

China famous brand water ring pump sk-6



Equipped PTO. pressure gauges, one water-gas separator, one oil-gas separator ,one oil tank reservoir, a lever inspection window and a piece of 6m suction hose , rear cover open , sewage tank lifting ,etc

The above information is for reference only. We can produce according to your needs so, If you have any questions you can contact me at any time.



Specification of DF Sewage Suction Truck DLKItemSpecificationItemSpecificationGeneralTruck NameSewage Suction Truck Overall Dimension (mm)6500×2120×2700Truck BrandDFGross / Curb Weight (kg)8495 / 4300Truck ModelDFA1080SJ11D3Approach / Departure Angle (°)24 / 12Max. Speed (km/h)90Front / Rear Overhang (mm)1210 / 1490ChassisChassis BrandDFChassis ModelDFA1080SJ11D3Wheel Base (mm)3800Leaf Spring8/10+7;
11/9+7

Traction System

4 x 2Quantity of Axles2Cab Capacity1-3Front / Rear Axle Load (kg)3390 / 5105TransmissionmanualFront / Rear Wheel Tread (mm)1770 / 1586
1831 / 1640Tyre Model7.50-16 12PR,
8.25-16 14PR,
7.50R16 12PR,
8.25R16 14PRQuantity of Tyre6Engine (Motor)BrandDFType of FuelDieselModelCY4102- Displacement (ml)3856Max. Power (KW/hp)100 / 136Emission StandardEuro 3-5-6Cylinder Stator4, all cylinders arranged vertically in lineMax Torque (N.m)420Quantity of Valves Per Cylinder4Maximum Torque Speed (rpm)1300-1500Cylinder Diameter × Stroke (mm)102 x 118Motor Rated Rotating Speed (rmp)2800Full Load Minimum Fuel Consumption Rate (g/KW.h)≤200Engine TypeElectric control high pressure common rail, water cooling, vertical.Compression Ratio17 : 1Noise From 1 Meter (dB)114Motor Net Weight (kg)430ABSyesEquipmentsTank Effective Capacity (L)5500Tank Materialcarbon / stainless steelTank Dimension (length x diameter) (mm)3780×1300Time to fulfill the tank (min)≤5Suction Height (m)≥10

NOTE:

1. Any part can be customized depending on customers' demand.

2. 12 months whole vehicle warranty

3. We could support you original spare parts. Besides, we can give assistance in the following days by email or telephone. If necessary, our outwork engineer could go for technical assistance.

4. MOQ: 1 unit




Looking forward to receiving your inquiry!
