• Specification：6596*2495*2465
• Trademark：Huaxing
• Origin：China
• Production Capacity：200units,Year

Basic Info.

Specification 6596*2495*2465 Trademark Huaxing Origin China Production Capacity 200units/Year

Product Description

Descriptionl Multi Types of Chassis Match
1. The upper can match with different Chassis of 2,3 or 4 axles
2. The upper can be designed to match with different Chassis as requirement.
l Mixing Drum Structure
1. The drum body and blades are made by quality wearable exclusive steel plate with light weight of Baosteel Q345B. And the drum is suit for transport both dry and wet materials.
2. The surface welding adopt manipulator double welding enables the strength structure and long service life.
3. Double pitch special designed blades ensure the fully mixing inside and low discharge surplus rate.
4. Unique design of agitator inclined angle with the whole drum make the lower and stable center of gravity, this makes the driving more steady and discharging more smooth, and gains better traffic ability.
l Hydraulic System
1. Closed circuit hydraulic system and constant hydraulic oil temperature controller
2. Adopt world famous brand hydraulic pump, hydraulic motor, reducer and radiator. Also provide muti options for different requirement.
l Water Supply
1. Pneumatic water supply system with large water tank which can wash different points including agitator drum, charging hopper and discharging hopper respectively.
2. Rational layout and elegant appearance of washing pipes make the washing more convenient and rapid.Specification

Model	Unit	8m3	10m3
Geometric Volume of Drum	m3	13.7	16.7
Material of drum & blades	/	Q345/B520JJ	Q345/B520JJ
Inclination Angle for Drum		15	12
Padding Rate	%	59.17	59.8
Residual rate	%	<0.2	<0.2
Charging Speed	m³/min	≥3	≥3
Discharging Speed	m³/min	>1	>1
Mixing Speed	r/min	0-18	0-18
Hydraulic Pump		Rexroth / Interpump	Rexroth / Interpump
Hydraulic Motor		Rexroth / Interpump	Rexroth / Interpump
Reducer		Chinese brand	Chinese brand
Radiator		Chinese brand	Chinese brand
Capability of water tank	L	450	450
Slum range	mm	50-210	50-210
Water supply pressure	Mpa	0.3	0.3
Max. External Diameter of Drum	mm	2300	2300
Length of the drum	mm	4720	5370
Upper-fixing length	mm	6596	7100
Subframe length	mm	5300	5800
Chute position	mm	1080	1080
Center of Gravity When full load	mm	2234	2895
Hopper height	mm	2522	2515
Upper-fixing height	mm	2645	2668
Overall dimension (L*W*H)	mm	6596*2495*2465	7100*2495*2668

Company Information

Xiangtan Huaxing Material Co., Ltd, started business since 1991, and was formally established as a registered company in 2002, with 5.3million RMB registered capital.
Before 2015, Huaxing focused on the domestic market, and is a qualified supplier of Jianglu group and XEMC in the military and mechanical products.
In 2015, Huaxing set up the international marketing department, specializing in exporting concrete construction machinery, mining Roadheaders, and the related spare parts and accessories. With manufacturing bases in Shenyang, Suizhou and Changsha cities.
Huaxing owns branches "Cahi "in Kiev Ukraine, and "Speedlane Trade Limited" overseas company. Mainly export to Pakistan, Ukraine, Russia, and other EU countries and Southeast Asian countries under our own brands "Speedlane" and '' HUAXING''.
Huaxing has got the CE certificate, and Ukraine's Coal Mining Safety certificate and permission. Cooperated with Ukraine largest energy company, DTEK group, the world top 500, and established a long term and friendly partnership.
Huaxing's enterprise value: Striving, Loyalty, Honesty and Altruism;
Huaxing's work concept: Tomorrow never comes; Never slug; Deliver positive energy!
Huaxing's mission:
One Stop Shop in engineering construction machinery;
China Machinery, Global Services!

Our Factory
