Sinotruck HOWO 6X4 8cbm Concrete Truck Mixer for Sale
Zhengzhou Focus Machinery Co., Ltd.- Certification：ISO9000, CCC, RoHS, CE
- Transmission Type：Automatic
- Emission Standard：Euro 3
- Displacement：9.7
- Payload：13.5t
- Fuel：Diesel
Base Info
- Model NO.：8cbm
- Drive Mode：6x4
- Maximum Horsepower：300-400hp
- Condition：New
- Weight：25000kg
- Dimension(L*W*H)：8715X2490X3800mm
- Power(W)：247kw
- Mixer Volume：8cbm
- Blades：Wear Resistant
- Hydraulic Driving System：Imported Famous Brand
- Water Supply：300L Tank with Reinforced Pipe
- Transport Package：Bulk Ship or Roro for 8cbm Concrete Transit Mixer
- Specification：ISO9001: 2008, CE
- Trademark：FOCUS
- Origin：Zhengzhou, China
- HS Code：8705400000
- Production Capacity：50 Sets Per Month
Description
| Truck name | HOWO Concrete mixing truck | |
|
Size parameters |
Dimension(L×W×H)(mm) | 8715*2496*3800 |
| Wheelbase(mm) | 3600+1350 | |
| Front overhang/rear overhang(mm) | 1500/2240 | |
| Approach angle/departure angle(°) | 16/26 | |
| Mix round cubage (m 3 ) | 8 m³ | |
| Obliquity of the drum( 0 ) | 15/13 | |
| Weight parameters | Gross Vehicle weight(kg) | 12800 |
| Permissible loading capacity | 12070 | |
| Vehicle + loading capacity (kg) | 25000 | |
| Axle load(kg) | 7000/18000 | |
|
Work parameters |
Rotary speed of the drum(r/min) | 0-18 |
| Input speed(m 3 /min) | ≥3 | |
| Output speed(m 3 /min) | ≥3 | |
| The rate of remaining | ≤1% | |
| Supply mode | Atmospheric type | |
| Volume of the water tank | 300L | |
| Hydraulic system | Pump | IMPORT PARTS |
| Motor | IMPORT PARTS | |
| Retarder | IMPORT PARTS | |
| Engine | Model | WD615.69 |
| Rated engine power(kw/rpm) | 336HP | |
| Max. torque N.m/(r/min) | 1280/1300-1600 | |
| Gear Box | Model | HW13710 |
| Brake system | Service brake | Dual circuit brake |
| Park brake | Spring energy air cut brake on front shaft and rear axle | |
| other | Max. speed(km/h) | 90 |
| Tire | 12.00R20 | |
| drive form | 6×4 | |
