Specialized Vehicle

Sinotruk 4X2 Asphalt Distribution Truck Bitumen Tank Truck

QINGTE GROUP SPECIAL VEHICLES CO., LIMITED
  • Fuel:Diesel
  • Certification:ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
  • Emission Standard:Euro 2
  • Condition:New
  • Color:as Customers′ Option
  • Warranty:6-12 Months

Base Info

  • Model NO.:ZZ1124G3916D1
  • Transport Package:Nude Packing
  • Specification:ISO
  • Trademark:SINOTURK
  • Origin:China
  • HS Code:8704224000
  • Production Capacity:3000 Units,Month

Description

Vehicle DescriptionVehicle modelAsphalt DistributorOverall dimensions (mm) 7200*2500*3180GVW (kg)Appro×12490Fact loading capacity (L)4000Mass in working order (kg)Appro×9500Max. Speed (km/h)95Chassis DescriptionChassis Model ZZ1124G3916D1CabStandard cabin with Left hand driveColorOptionalAllowable person in cab2Wheel base (mm)4500Front/Rear track base (mm)1506/1466Front/Rear overhang (mm)1032/2068Number of axles2AxleFront axle2320Rear axle3480Traction system4x2Operation control systemPower steeringBraking systemFull airElectric system24VTransmissionMechanical gear box 5 speeds + one rearSpring plate6/8+4Tire specification9.00-20Tire quantity6+1Engine DescriptionEngine model YC4E140-42Emission standardEuro 2Exhaust/output4260/103Horse power140Up-parts DescriptionAsphalt tank Outline Dimension (mm)3160/2160/1570Asphalt tank Inner Dimension(mm)2660/1660/1070Insulating layer thickness (mm)50Asphalt tank Total Volume(L)4000Hydraulic pumpCBQ550-LProportional valveTaiwan EFBG-03-160-HFAsphalt pumpQGB680Hydraulic motor for asphalt pump05-110-BD31Heating SystemItalian burner RielloHeat-transfer oil pump25-25-160Control SystemSIEMENS   CLW-39-01Generator5.5KW gasoline engine generatorNumber of nozzle30-39Spray mediumHot asphalt/ Hot modified asphalt/ Cutback asphalt/ Emulsified asphaltSpray width(m)4.5-6Spray amount(L/m2)0.2-2Working Condition:1,Altitude: 0-4500m
2,Temperature: -350C~+450C
3,Relative humidity: 80%
4,Wind force: ≤8 degreeSinotruk 4X2 Asphalt Distribution Truck Bitumen Tank Truck
Sinotruk 4X2 Asphalt Distribution Truck Bitumen Tank Truck


2. Our Factory
SINOTRUK has an annual output of 180,000 vehicles and 200,000 engines capacity.

3. Packing: Nude packing after painting wax or according to your requirement.
Shipping:By bulk cargo carrier, RORO


4. Our Advantages
(1)Competitive Factory Price and Excellent Quality
(2)More than 20 years' experience as a manufacturer
(3)Products Quality Certification SGS CCC ISO
(4)Perfect after-sale service
(5)Customized products available with us
(6)Export to more than 90 countries and regions

5. FAQ
Q1. : Are your manufacturer ?
A : Yes! We can totally manufacture the trucks as you required.
Q2. Do you have a good orgonization of shipping vessle ?
A: Yes, we have a good and long term cooperation with the world first class famous shipping company line,like MSK,PIL,SUNSHINE SHIPPING,ETC.The order over 500 units of vehicle,we will lease a vessel.
Q 3 : How about your warranty items?
A : We supply original spare parts of our vehicles, if you need, we will show you spare parts list for your choosing to make sure daily maintain of your vehicles.
Q 4 : Can I be your agent in my country?
A : It is Ok if the order is appropriate, we looks forward to long-term cooperation with you.
Q 5 : What is the delivery time and payment term?
A : Our common products delivery time is 10-35 working days except some definitely special vehicles. We accept 30% T/T deposit and 70% balance T/T or 100% L/C. More details, please contact with our salesman.


6. Warranty
(1) One year quality guarantee or within 100000km, which comes the first.
(2) Other spare part could be supplied by OEM at cost prices.
(3) Regularly callback to know the vehicle's working status.
(4) The overseas engineers are always ready to deal with unexpected needs.


7. Company information
China Truck International Ltd is one of the main exporters of Chinese trucks which is authorized by Ministry of Commerce
Staff of our company can provide the trucks meeting the requirement of customers at the best price. We have many years of experience in exporting trucks. If you want to buy any truck, trailer or truck parts,please contact us!
We sincerely hope to cooperate with you to expand market in your country!
