• Fuel：Diesel
• Drive Wheel：6×4
• Brand：Dongfeng
• Models：Medium
• Usage：Compression Type
• Condition：New
• Product Name：Garbage Compactor Truck
• Chassis Brand：Dongfeng
• Color：White
• Driving Type：6X4 Driving Type
• Cab：One and Half Cab
• Tires Number：10+1
• Capacity：3-6 Cbm
• Engine Power：280HP
• Transport Package：Wax Covered
• Specification：9800x2500x3150 (mm)
• Trademark：CLW
• Origin：China
• Production Capacity：500 Units , Month

Main Technology Parameter

Product Name

16m3 garbage compactor truck

Driving Type

 6x4,left /right hand drive

Color & Logo

Accept customization

Weights

G.V.W(kg)

25000

Curb weight(kg)

10000 (Approx.)

Dimensions

Wheelbase(mm)

4600+1350

Overall Dimension(mm)

9800×2500×3150(Approx.)

Garbage collection capacity

16 m3

Engine

Engine type

4 stroke ,Water cooled, direct injection, turbo charger

No. of cylinders

6 cylinders

Displacement(L)

9.26L

Max. output (hp/kw)

280/205

Emission standard

Euro 3  (Euro 4 /5 optional)

Drive Line

Transmission

FAST 9 speeds ,9 forwards,1 reverse gear,manual operation

Steering

Power steering

Brake

Air brake

ABS

With

Cab

Cabin

One and half cab,three passengers (2+ driver) all welded steel cab

Standard configuration

Air conditioner ,heater, central lock ,power window .USB,AM/FM radio, two sun reflectors

Axle

Front axle

5 tons

Rear axle

 20 tons

Tire specification

Tire specification

10.00R20 steel wire tire,10 tires+1 spare tire

10m3 garbage compactor truck

Box volume

16m3 / 18m3

Box material

Side 5mm,bottom 5mm

Sewage tanker

200L

Compaction ratio

By volume not less than 5:1

Work cycle time

Not more than 35 seconds

Hydraulic system pressure

16Mpa
