Specialized Vehicle

China 4X2 Drive 4-6L/6-8L New Euro 3/Euro 2 Emission Standard Sprinkler Tank

QINGTE GROUP SPECIAL VEHICLES CO., LIMITED
  • Volume:5001 - 10000L
  • Certification:ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
  • Emission Standard:Euro 2,Euro 3,Euro 4
  • Sprinkling Area:12 - 16m
  • Transmission Type:Manual
  • Payload:20T

Base Info

  • Fuel:Diesel
  • Drive Wheel:4×2
  • Engine Capacity:6 - 8L
  • Condition:New
  • Color:as Your Request
  • Warranty:One Year or 10000km Which Comes First
  • Transport Package:Nude Package After Printing Wax
  • Specification:Heavy Truck
  • Trademark:HOWO
  • Origin:China
  • Production Capacity:3000unites,Month

Description

Truck Brand

SINOTRUK-HOWO

Driving Type

Left hand driving

Dimension(Lx W xH)

9896×2500×3680

Approaching angle/Departure angle(°)

10/12

F/R track base(mm)

1939/1958

Tank capacity( m3 )

20

Medium

Diesel

Wheel base (mm)

4600+1350

Max speed(km/h

90

Curb weight(kg)

8000

Loading Weight(kg)

11890



Engine

(Steyr technology, made in China)

Model

WD615.62,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection

Fuel type

Diesel

Horse Power, max(kw/rpm)

266HP

Emission

EURO II

Fuel tanker capacity (L)

350

Transmission

Model

HW13710,10 forward&2 reverse

Brake system

Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels

Auxiliary brake

Engine exhaust brake

Steering system

Model

JL80Z

Front axle

Steering with double T-cross section beam

Rear axle

Pressed axle housing, central double reduction with differential locks between axles and wheels

Color

Optional

Tire

11.00-20

Tire quantity

10+1 spare

Electrical system

Battery

2X12V/165Ah

Alternator

28V-1500kw

Starter

7.5Kw/24V

 Cab

L2000 cab, all-steel forward control,55ºhydraulically tiltable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers HOWO76 cab with one sleeper and air conditioner, all-steel forward control,55ºhydraulically tiltable to the front, 2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers



Our Advantages

(1)Competitive Factory Price and Excellent Quality
(2)More than 20 years' experience as a manufacturer
(3)Products Quality Certification SGS CCC ISO
(4)Perfect after-sale service
(5)Customized products available with us
(6)Export to more than 90 countries and regions

Our Main Products

Our main products include full series products of CNHTC(HOWO,STR,Golden Prince,etc.),buses, trailers, including dump truck, tractor truck, concrete mixer truck, sprinkler truck,water/Oil tank truck, truck mounted crane, concrete pump truck.etc, low bed semi-trailer,flatbed semi-trailer, bulk cement semi-trailer, skeleton semi-trailer and spare parts for them.

In Addition, Happy to tell all of our customers, in order to meet all the requires from different countries, we have built used truck second hand truck business, we will buy some second hand truck with good condition and put them in our warehouse so that you can choose the trucks you liked when you are in China. If unconvenient for you, we can choose for you! Only good condition, good price, earn long-term business!

China 4X2 Drive 4-6L/6-8L New Euro 3/Euro 2 Emission Standard Sprinkler TankChina 4X2 Drive 4-6L/6-8L New Euro 3/Euro 2 Emission Standard Sprinkler TankChina 4X2 Drive 4-6L/6-8L New Euro 3/Euro 2 Emission Standard Sprinkler TankChina 4X2 Drive 4-6L/6-8L New Euro 3/Euro 2 Emission Standard Sprinkler Tank
FAQ

Q1: I don't want this configuration.
   A:  The configuration can be changed according to your needs

Q2: Minimum order quantity?
   A:  MOQ is 1 unit.

Q 3:  Production period?
   A:  (Truck & trailer) Within 30 days since the moment we got your down payment
        (Parts)  Within 7 days since the moment we got your down payment

Q 4: Payment term?
   A:  (Truck & trailer)  30% T/T as deposit, the balance should be paid before delivery. or L/C
         (Parts)  100% T/T should be paid before delivery

Q 5: Shipping?
   A:    (Truck & trailer)
         by container or RoRo/Bulk shipment. (South America, Middle East, Africa, Oceania etc.)
         by road or railway.(Russia, Mongolia, Kazakhstan, Uzbekistan , Vietnam, Laos  etc.)
        (Parts)
         by international courier service, such as DHL, TNT, UPS, or Fedex. The goods above $1000 can be shipped by sea

Q 6: Can you supply some quick-wear truck or semi trailer parts ?
   A: Yes, we can supply truck and semi trailer parts as your request,such as oil filter, fuel filter, air filter, traction, traction pin, balance   beam and semi-trailer plate spring, hanging accessories, turntable, all kinds of trailer brake pads,   brake pan, bearings etc.

Warranty

(1) One year quality guarantee or within 100000km, which comes the first.
(2) Other spare part could be supplied by OEM at cost prices.
(3) Regularly callback to know the vehicle's working status.
(4) The overseas engineers are always ready to deal with unexpected needs.

China 4X2 Drive 4-6L/6-8L New Euro 3/Euro 2 Emission Standard Sprinkler Tank
