• Vacuum Pump Type：Re-200vt Tss6
• Maximum Vacuum(Kpa)：78.4-58.0
• Air Compressed Engine：Vs230, Bdw-972
• (Kpa) Maximum Pressure：196
• Transport Package：Nude
• Specification：EMARK, GCC, VCA
• Trademark：CIMC
• Origin：China
• HS Code：8704230000
• Production Capacity：200 Units Per Year

NO.Project NameDetailed description1Whole tank vehicleVehicle NameMulti-function joint suction vehiclesModelCIMC5310GXWChassisHeavy Duty TruckWheelbase4200+1350The total mass kg31000Load weight kg8500Dimensions (mm)10760×2496×39602EngineEmission StandardsEuro IIIPower kw221Fuel TypeDiesel fuel3Material tankTank volume m318Tank size (diameter × length) mm2100×5410Tank material16MnHigh strength steelTank wall thickness mm6Feed valve6InchLift the tank≥50Degree4Vacuum systemVacuum degree bar-0.5Maximum air flow m3 / h5709Mm maximum particle material15Pumping distance m≥505Discharge SystemWorking pressure bar2The maximum displacement m3 / h500Discharge capacity t / h30-70Discharge height m15-30Discharge valve4InchThe remaining rate ‰≤26Dredge systemPressure bar160Flow l / min122Hose length m607Boom System Angle of rotation300FunctionCan be pulled back and forth, up and down, left and right rotationDiameter6 inches
We have different chassis model and tank volume to meet different clients' requirement.
1, Engine emission standard: Euro 2/Euro 3/Euro 4/Euro 5
2, Chassis brand: ISUZU, Sinotruk, Shacman
3, Tank volume: 16m³, 23m³
