• Model NO.：CLW
• Bearing Capacity：Large
• Car Type：Van
• Condition：New
• Description：Hino Ice Cream Truck Heavy Duty 8X4 35cbm Hino Tru
• Other Name：Refrigeration Truck, Ice Cream Truck, Refrigerate
• Color：Red, White, Green, Yellow, Blue,
• Drive Model：4X2 6X4 8X4 6X2 Truck
• Van Material：FRP(Fiber Reinforced Plastics)
• Loading Medium：Seafood,Fish, Meat, Ice Cream for Truck Refrigera
• Tire：7.00r15 10pr Truck Refrigerator Transport
• Volume of Refrigerated Van：15cbm, 20bm,25cbm,30cbm,35cbm,40cbm
• Brand：Dongfeng, Df, Dfl, HOWO, Sinotruk, Faw
• Working Temperature：-18 °c-15°c
• Transport Package：RO-RO Bulk Naked Contaienr
• Specification：ISO, CCC, CE CE, ASME, ASTM, EEC, ASME, ASTM, EEC
• Trademark：CLW BRAND
• Origin：Hubei China
• HS Code：8704230090
• Production Capacity：1000 Set Per Year

ModelF600Temperature rating container-18°C~+25°C Cooling capacity(W) 3200(-18°C) Volume of container(m³) 21~32(-18°C) Voltage DC24V Compressor TM16(163cc/r) Refrigerant R404a 2.4~2.5Kg Evaporator dimensions 1473*644*230mm Condenser dimensions 1265*555*415mm

1.Hubei Chengli Special Automobile Co, ltd which is appointed by Ministry of Industry and Information Technology of China, is a big manufactureeer producing all kinds of special trucks and semi-trailer.
2. Our company cooperates with famous chassis manufactureer, such as DONGFENG, FAW,SINOTRUK, JAC, SHACMAN, FOTON,CMAC,  and etc. We can produce more than 300 kinds of special trucks and semi-trailer.
3.Chengli take customer's  satisfaction as the top requirement. All of the trucks and semi-trailer sell to Africa, South-east Aisa, Australia, Middle-east and other place.
4.We serve the best service for each client.


Real benefits for the customers

1,working ambient temp.width, can work very well during -25*C to +55*C ambient temperature,and the the temperature in container can lower to -20*C,keep the safe transportation under any condition.
2,Very easy be installed and operation, digital contrller in cab,easy be setting and check.
3,High quanlity Maintence parts provide in time ,exactly

Beliving ChengLI special automobile -----the power of the world!

1. we are professional manufacturers for the special vehicles. We can supply all brands of special trucks, such as north Benz(beiben), Faw, Foton, Shaanxi, Sinotruck, JAC, Jmc, Dongfeng, mitsubishi, fuso
2.The drive type could be 4X2, 4X4, 6X2, 6X4, 6X6, 8X4
3. We can provide LHD (left hand drive) or RHD (right hand drive) vehicles.
4. OEM Ability (We can produce according to your demand, the material, the size,  the color and the logo is optional for you)
5. Fast Delivery: 1-10 working days after payment, safe and quick delivery.
6. Good Service: Please feel free to inquire us any problems about CLW TRUCK

Packaging & Shipping

Delivery days :7-10days
Shipping : naked waxing coat ;small one into 20` GP or 40` GP ,big type can be carried by bulk carriers or ro-ro ship or you pick
Payment terms :30% depoisite T/T
Our company offer Transportation insurance for customer. To ensure customer's prdocts arrival at the destination new and safe.
It can be assembled and disassembled

Below specification is just for your reference. More information of our Refrigeration Van Truck please feel free to contact with Ms. Kitty Zhen. We will customize the truck according to your requirement.

DescriptionHINO Refrigerator Trucks/8X4 HINO Refrigerated Trucks/
HINO Refrigeration Truck/
HINO Ice Cream Truck   heavy duty 8X4 35cbm HINO truck refrigerator transport
Drive Model
4X2,6X4,6X2,8X4
Vehicle Main           Dimensions
(L x W x H)mm
11980*2540*3950
Wheel base (mm)
1850+4300+1410mm
Wheel track (front/rear) (mm)
1085/1550
Weight in KGS
Tare Weight
14200
Loading Capacity
16670
Max. driving speed(km/h)
100
Engine
Model
P11C-UJ
Type
4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
Horse Power(HP)
350HP
Displacement
10.52L
Max Output Power
259KW
Emission standard
Euro III
Gearbox
12JSD160TA 12forwards& 2 reverse
Clutch
Reinforced diaphragm clutch, diameter 430mm
Tire
7.00R15 All steel radial tire, 1pc including 1 spare tire
Brakes
Service brake: dual circuit compressed air brake                                                                                       Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake
Steering Gear
power steering, hydraulic steering with power assistance
Refrigerator Box Equipment
Box Length
9435*2345*2400mm
Van Material
GRP/Steel/Aluminum Alloy in the surface, foam in the middle, thickness 80-100mm
Temperature
-20-0 Celsius
Brand
Chinese/US/Korean refrigerator for option
Application
Seafood, Fish, Ice Cream, Meat and other need cooling food.
