4*2 Qinglin High-Altitude Operation Trucks
Chengli Special Automobile Co., Ltd.- Type：Z
- Certification：ISO9000, CCC
- Emission Standard：Euro 2
- Hoesrpower：150-250hp
- Payload：2-3t
- Fuel：Diesel
Base Info
- Model NO.：QL11409MFR
- Transmission Type：Manual
- Drive Wheel：4x2
- Condition：New
- Brand：Isuzu
- Engine Brand：Ql
- Horse Power：130HP, 190HP, 210HP
- Exhaust：5193ml
- Color：White, Yellow, Blue...as You Like
- Working Height：15m, 16m, 17m, 18m
- Working Platform Rating Allowable Passen：2
- Working Platform Dimension：1100*570*1000mm
- Max Speed：90km,H
- Warranty：12 Month for Three Key Parts( Engine Gearbox, Axle
- Transport Package：Naked or Waxed Before on Board
- Specification：CCC, ISO9001
- Trademark：ISUZU
- Origin：Hubei, Suizhou
- HS Code：8705909090
- Production Capacity：1000set,Month
Description
| Item | unit | parameter | ||
| Vehicle model | ISUZU 4*2 High Altitude Operation Trucks | |||
| Chassis model | QL11409MFR | |||
| Overall dimensions | mm | 8400X2470X3810 | ||
| Curb Weight | kg | 13195 | ||
| Payload | 205 | |||
| Wheel base | mm | 13390 | ||
| F/R track base | 1335/2565 | |||
| Exhaust/hp | ml/ps | 5193/190 | ||
| Max speed | km/h | 90 | ||
|
Tire specification |
9.00R20 |
Engine type |
4HK1-TCG40 | |
|
Traction system |
4*2 |
Transmission |
6-speed with over drive | |
|
Number of axles |
2 |
Axle Load |
4350/9040 | |
| Leaf Spring | 7/7+5 | Allowable passengers in Cab | 2/3 | |
| Engine | QL ,6-cylinder in-line with water cooling | |||
| Equipment |
1.Equipped with working bucket, hook, 4 H-type hydraulic outriggers, 2.Equipped with three folded arms, 360 slewing, hydraulic control, on the truck/under the truck operating |
|||
