- Model NO.:CLW
- Transmission Type:Manual
- Drive Wheel:4x2
- Condition:New
- Chassis Brand:JAC, Dongfeng, Sinotruk,Faw,Beiben
- Engine Model:Isf2.8s3129t
- Wheel Base (mm):3360
- Wheel Track (Front/Rear) (mm):1085,2100
- Approach/Departure Angle(°):19,15
- Max. Driving Speed(Km/H):95
- Horse Power(HP):130HP
- Tire:8.25r16 All Steel Radial Tire, 1PC Including 1 SPA
- Working Platform:360°turning, H-Shape Legs 360°
- Boom Type:Straight,Foldable
- Transport Package:Naked or Waxed
- Specification:CCC, ISO, SGS, BV
- Trademark:CLW
- Origin:Hubei China
- HS Code:870190900
- Production Capacity:1000units,Month
Cabin | FOTON High up Truck/FOTON High Truck/FOTON High-Altitude Operation Truck/FOTON High Platform Truck/FOTON Aerial Working Truck |
Drive Model | 4X2 6X4 6X2 8X4 8X6 |
Vehicle Main Dimensions | (L x W x H)mm | 7385*1980*3170 |
Wheel base (mm) | 3360 |
Wheel track (front/rear) (mm) | 1085/2100 |
Approach/Departure angle(°) | 19/15 |
Weight in KGS | Curb Weight | 5920 |
GVW. | 6245 |
Max. driving speed(km/h) | 95 |
Engine | Brand | Cummins |
Model | ISF2.8s3129T |
Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
Horse Power(HP) | 130HP |
Displacement | 2.78L |
Max. Output Power | 96KW |
Emission standard | Euro III |
Gearbox | 5 forwards& 1 reverse |
Clutch | Reinforced diaphragm clutch, diameter 430mm |
Tire | 8.25R16 7.00R16 9.00R16All steel radial tire, 1pc including 1 spare tire |
Brakes | Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake |
Steering Gear | power steering, hydraulic steering with power assistance |
Equipment |
Working Platform | 360°turning(left or right), H-shape legs 360° |
Extendable boom sections | 2/3/4 |
Max Lifting Weight | 990KG 1000KG,1500KG,2000KG |
Max. Working Radius | 10m,8m,12m,14m,13m,15m,16m,17m,18m |
Landing Leg | 4 legs |
Boom Type | Straight/Foldable |
Lifting Max. Height | 8m,10m,12m,14m,16m,18m,20m, |
