• Model NO.：CLW5140
• Transmission Type：Manual
• Payload：10ton
• Fuel：Diesel
• Drive Wheel：4×2
• Engine Capacity：＜4L
• Condition：New
• Description：Dongfeng 145 Water Truck
• Volume of Tank：10000L, 12000L, 14000L, 15000L Wat
• Steel Grade：Q235B Carbon Steel or Stainless Steel
• Engine：160HP,190HP,210HP Dongfeng Water Tank Truck
• Top Manhole：API Standard, 500mm
• Driving Type：LHD or Rhd
• No.of Sleeper：with One Sleeper or Without Sleeper
• Air Conditioner：with A,C or Without A,C
• Driver Seat：Air-Supporting Driving Seat
• Brand：Dongfeng Road Wash Water Tank Truck
• Transport Package：Waxed Before on Board
• Specification：ISO, CCC, CE, ASME, ASTM, EEC
• Trademark：CLW BRAND
• Origin：Hubei Suizhou
• HS Code：87053010
• Production Capacity：500unit,Month

DescriptionDongfeng 145 4X2 Water tank truck
 Drive Model4X2ChassisEQ1110GLJ3Number of axles2Vehicle Main DimensionsDimensions(L x W x H)(mm)8000×2470×2850Wheel base (mm)4500Overhang (front/rear) (mm)1250/2050Wheel track (front/rear) (mm)1900/1800Approach/Departure angle(°)30/15Weight in KGSCurb Weight5700GVW.11495Max. driving speed(km/h)90EngineModelB170 33Type4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-coolingHorse Power(HP)170HPengine capacity(ml)5900Emission standardEuro IIIGearbox6 forwards & 1 reverseClutchReinforced diaphragm clutchSteering GearPower steering, hydraulic steering with power assistanceFuel tank (L)200Tire9.00-20tire , 6 + 1(spare)Brakesdual circuit compressed air brakeTankMaterialQ235A Carbon steelMediumWaterLoading Capacity (m³)10Overall dimensions(mm)4600×1800×1200Thickness(mm)5Standard
Equipment
 1.Equipped with front,rear,side sprinkler (sprinkling width>14m )
2.Equipped with rear working platform with water cannon
which can be turned all-round (range>28m),can be adjusted into flinging, heavy rain,
light rain, drizzle model, with security barrier.
3.Equipped with CLW  pump(suction lift>6m)
4.Equipped with fire valve, water valve, and filter gauzeoptional
Equipment5..Firefighting pipe
6.Firefighting Pump
7.The painting
