• Model NO.：WZJ5256GXY
• Vacuum Pump Type：Re-200vt Tss6
• Maximum Vacuum(Kpa)：78.4-58.0
• Air Compressed Engine：Vs230,Bdw-972
• (Kpa) Maximum Pressure：196
• Transport Package：Nude
• Specification：EMARK, GCC, VCA
• Trademark：CIMC
• Origin：China
• HS Code：8704230000
• Production Capacity：200 Units Per Year

Vehicle modelJTJ5256GXYVehicle nameSuper suckerChassis typeBEI BEN 6X4Engine modelWP12.400E50Payload capacity(m3)12.08Maximum load quality(kg)8285Vehicle kerb mass(kg)16520Vehicle total mass(kg)25000Length(mm)10940Width(mm)2480Height(mm)3740Minimum turning diameter (m)21Maximum vehicle speed(km/h)90Grade ability(%)22Geometric volume of the tank(m3)14Nominal diameter of the tank(mm)2000Working pressure of tank(MPa)-0.07~+0.2Design internal pressure(MPa)0.2Design external pressure(MPa)0.1Ability of suction(t/h)About 30~60(Horizontal distance 5m,Vertical depth 3m,With 2 elbows)Ability of pressure(t/h)About30~60(Horizontal distance 5m,Vertical depth 20m,With 2 elbows)Maximum angle of lifting the tank(o )45Power take-offs  modelQD60;QH70CHydraulic system control modeMachine - hydraulic linkageHydraulic reservoir tank volume(L)70Control valveZS1-L15E-OT-OT2.Vacuum pump technical parameters:Vacuum pumpVacuum pump modelASE-200VTVacuum pump nameSingle stage dry high pressure roots vacuum pumpMaximum vacuum(kPa)-78.4Rated speed(r/min)1450(Current speed 1740r/min)Airflow(m3/min)48.6Vacuum degree of the relief valve(kPa)-65~-70

3.Air compressor technical parameters:Air compressorModelVS.230 Non-lubricated air compressorRated speed(r/min)900(Current speed 880r/min)Displacement(m3/min)9Maximum pressure(kPa)196

4.Hydraulic gear pump technical parameters:Hydraulic gear pumpModelCBT-E550 Hydraulic gear pumpNominal displacement(ml/r)50Nominal pressure(MPa)21Rated speed(r/min)2000Minimum speed(r/min)1200Working speed(r/min)1200(Engine speed 920r/min)

5.Lift cylinder technical parameters:Lift cylinderModelCylinder HYVA FC137-03840-Nominal pressure(MPa)22Effective diameter(mm)Φ99/Φ118/Φ137Stroke(mm)3840ManufacturerHYVA

6. Technology parameters of cylinder for opening the back cover:Back cover oil cylinderModelHSG-L01-50/25Nominal pressure(MPa)16Cylinder diameter(mm)Φ50Stroke(mm)300The manufacturerSichuan chang jiang hydraulic parts co., Ltd. ChinaEffective volume of the tank:12.08
cubic metres.
Tank dimensions:
Tank length:4,770mm,
Internal diameter: 2,000mm.
Tank transport medium : CDQ (coke dry quenching powder), Density: 720 kilograms/M.

Side protection bars material:Q235A, Connected with the beam by bolts.
Back protection bar material: Q235A,Connected with the beam by bolts.

Width:40mm, Height:120mm Ground clearance: 510mm
