Specialized Vehicle

China Make Reefer Container Truck 4X2 Fish Chiller Truck Jmc Frozen Food Refrigerator Truck

CLW Heavy Industry Co., Ltd
  • After-sales Service:Lifetime Technical Support, Parts Supply etc
  • Warranty:1 Year
  • Certification:ISO9000, CCC, TS16949, EPA, EEC, RoHS, CE
  • Payload:20T
  • Emission Standard:Euro 3
  • Transmission Type:Manual

Base Info

  • Model NO.:CLW
  • Horsepower:150-250hp
  • Fuel:Diesel
  • Bearing Capacity:Medium
  • Car Type:Van
  • Condition:New
  • Description:China Make Reefer Container Truck 4X2 Fish Chiller
  • Brand:Dongfeng Sinotruk HOWO Faw Foton JAC Forland Sham
  • Color:White Blue Red Yellow Jmc Refrigerator Compressing
  • Wheel:4wheels, 6wheels, 8wheels, 10wheels, 12wheels, 14wheels
  • Driving Model:4*2 6*4 8*4 6*2 8*2 4*4 Jmc Refrigerator Compress
  • Engine Model:Dongfeng Deutz Ranault, Yc Screfrigerator Compress
  • Material:Carton Steel Q235B, Stainless Steel 314, Alloy, Alum
  • Exhaust/Power(Kw):137, 150, 160, 170, 180 HP, 200HP, 250HP Refrigerator Co
  • Capacity (Load):5t, 10t, 15t, 20t, 25t, 30t, 35t, 40t, 45t, 50t, 55t, 60t
  • Filling Medium:Medicine, Fresh Meat, Fruit, Vegetable, Chicken, Fi
  • Transport Package:RO-RO Bulk Naked Container
  • Specification:ISO, CCC, CE CE, ASME, ASTM, EEC, ASME, ASTM, EEC
  • Trademark:CLW BRAND
  • Origin:Hubei Suizhou
  • HS Code:87163190
  • Production Capacity:100000PCS,Year

Description

Main specificationProduct model and nameChina manufacture JMC refrigerator truck cooling JMC freezer truck low price JMC refrigerated van truckGross weight(Kg)5790Drive type4x2Payload(Kg)2500Overall dimension(mm)5990×1950×2880Curb weight(Kg)3160Cab seats2Approach/departure angle(°)27/16Front/rear hang(mm)1015/1615Axle No.2Wheelbase(mm)3360Axle load(Kg)2200/3590Max speed(Km/h)80Chassis specificationChassis modelJX1060TG24ManufacturerJMC Motor Co.,LtdBrand nameJMCDimension(mm)5825×1880×2020Tyre specification7.00R16LTTyre No.6Steel spring number7/5+5Front track base(mm)1385Fuel typeDieselRear track base(mm)1425Emission standardEuro 4Transmission5 forward gear,1 reverse gearCabSingle row, luxurious interiors and seats with power steering. Air condition is optional.Engine modelEngine manufacturerDisplacement(ml)Power(Kw)JX493ZLQ4JMC Motor Co.,Ltd277180PerformanceVan body size4200X1750X1750Truck body volume(m³)3(3 TON)Lowest refrigeration temperature(ºC)-5 to -10 CentigradeFeature and ApplicationThe refrigerator truck is the closed van truck that is used to transport the frozen or fresh goods. This truck is made up of vehicle chassis, Polyurethane insulation van, refrigeration unit and temperature recorder. It is commonly used to transport the frozen food, dairy products, vegetable and fruit and vaccine medicine etc. For the special requirements of trucks,such as the meat transportation, the meat hook, aluminum alloy guide rail and ventilation slots etc. parts can be chosen and installed.
