• Model NO.：CLW high altitude operation truck
• Payload：2-3t
• Fuel：Diesel
• Transmission Type：Manual
• Drive Wheel：4x2
• Condition：New
• Description：High Altitude Operation Truck
• Working Height：12m, 13m, 14, 15m, 16m
• Engine Model：Dongfeng, Deutz Ranault,Yc Sc Wd
• Chassis：Dongfeng Sinotruk FAW Foton JAC Shacman
• Tire：7.00-15,7.00r15
• Working Platform Allowable Person：2
• Working Platform Dimension：1100*570*1000mm
• Rotate Degree：360 Degree
• Shipment：Naked with Wax
• Transport Package：Naked Package and Waxed Before on Board
• Specification：ECE ISO GCC CCC ASME ASTM
• Trademark：CLW
• Origin：Hubei China
• HS Code：8701909000
• Production Capacity：100000PCS,Year

Description
 High-altitude Working Truck
Drive Model4X2ChassisQL10508HWRYNumber of axles2Vehicle Main DimensionsDimensions(L x W x H)(mm)7400×1980×3100Wheel base (mm)3360Overhang (front/rear) (mm)1015/2180Wheel track (front/rear) (mm)1385/1425Approach/Departure angle(°)24/12Weight in KGSCurb Weight4975GVW.5300Max. driving speed(km/h)95EngineModel4JB1-TC1Type4-stroke direct injection , 4-cylinder in-line with water cooling, turbo-charging and inter-coolingHorse Power(HP)95HPengine capacity(ml)2771Emission standardEuro IIIGearbox5 forwards & 1 reverseClutchReinforced diaphragm clutchSteering GearPower steering, hydraulic steering with power assistanceFuel tank (L)180Tire7.00-15tire , 6 + 1(spare)Brakesdual circuit compressed air brakeAllowable passengers in cab:5Working platformMaterialQ235 Carbon steelworking platform dimension1100*570*1000mmMaximum operation height16MMaximum operation radius7M Max lifting weight800kghydraulic system pressure<=16MPaworking platform rating allowable passengers2Max load capacity of the square platform250KgElectric system24VOtherMax operation height>=16m
Max operation radius>=7m
Max working platform height>=14.5m
360°turning(left or right),4 H-shape legs. 1.5 ton crane
Insulating material in the cage
The cage can be operated both in the air and on the earth

Drawing of 16M High-altitude Working Truck

Chassis dimension7400×1980×3100mmworking platform working platform dimension1100×570×1000mmThe maximum height from the ground14300mmMax Operating Radius6920mmleg lateral span2680mm longitudinal span2730mm   Max lifting height6300mm

Exporting

Chengli special automobile Co., Ltd is an automobile manufacturer , the company is a marketing enterprise of various heavy automobile brands, integrating international and domestic trade. Besides, the company has established a good relationship with domestic and overseas customers from Africa, South America, the Middle East and South Asia, winning a universal recognition and trust from the oversea customers and contributing to China trucks' entrance to the international market.
1.58 sets of mili tary water trucks for national defense
2. Dump trucks in support of the United Nations
3. Fuel tank trucks exported to Sudan
4.78 sets of water truck exported to Nigeria
5. Dump trucks exported to the Ivory Coast, Kazakhstan
6.108sets of trucks exported to Libya
7.36 sets of dump trucks exported to North America
8.218 sets of garbage trucks exported to West Africa
9.60sets of water trucks exported to Congo
10. Garbage trucks exported to Vietnam
11.98 sets of dump trucks exported to Ghana

Product advantage:
1. Factory export department directly sale
2. Export experience more than 12 years
3. Cheap / competitive price, high quality, you get more than your paid
4. With CCC, ISO, BV approved
5. The heart of the service, rational design

We are confident and committed to providing our customers with the best qualityand service all the time.
If you are interested in our trucks, pls contact me, I will send our best quotation to you!



WELCOME TO VISIT OUR FACTORY AND PLACE YOUR ORDER!
