- Model NO.：P6158 with hard door
Battery | 12xT105(185Ah@5hr rate) | 16xT105(185Ah@5hr rate) | 16xT105(185Ah@5hr rate) |
| Motor | 5KW Chinese motor for 60minutes | 5KW Chinese motor for 60minutes | 5KW Chinese motor for 60minutes |
| Controller | Curtis 1209 (400A@2minutes) | Curtis 1205 (350A@2minutes) | Curtis 1244 (400A@2minutes) |
| Performance |
|
|
|
| Passenger capacity | 14 | 14 | 14 |
| Range (loaded) based on flat road at a speed of 20km/h(km) | >80 | >100 | >100 |
| Max. speed | 45 | 40 | 40 |
| Minimum turning radius (m) | 5.35 | 5.35 | 5.35 |
| Max. climbing ability (loaded) | 25% | 20% | 20% |
| Max. movement after brake | ≤4m | ≤4m | ≤4m |
| Max. loading weight | 1120kgs | 1120kgs | 1120kgs |
| Net weight | 1270kgs | 1390kgs | 1390kgs |
| Dimensions |
|
|
|
| Overall dimensions (mm) | 5000x1490x2050 |
| Min. ground clearance (mm) | 135 |
| Wheelbase (mm) | 2710 |
| Front wheel tread (mm) | 1222 |
| Rear wheel tread (mm) | 1185 |
