- Model NO.:GLS
- Drive Wheel:4x2
- Hoesrpower:150-250hp
- Condition:New
- Transport Package:Nud Packing, Maxed,Loading in The Container,Roro S
- Trademark:lisheng
- Origin:Suizhou, Hubei, China
- Production Capacity:20unit,Day
Main specifications |
Product model,name | 5080GQW sewage cleaning truck |
Gross weight(Kg) | 8495 | Driving type | 4*2 |
Payload (Kg) | 3000 | Overall dimension (mm) | 6860×2040×2800 |
Curb weight(Kg) | 5300 | Cab seats (man) | 2/3 |
Approach/departure angle (°) | 24/13 | Front/rear hang(mm) | 1085/1960 |
Axle No. | 2 | Wheelbase (mm) | 3815 |
Axle load(Kg) | 3060/5435 | Max speed(Km/h) | 90 |
Chassis specifications |
Chassis model | HFC1081K2F | Manufacture | Anhui JAC Automobile Co.,Ltd |
Brand name | JAC | Overall dimension (mm) | 6810×1995×2216 |
Tire specification | 8.25-16 14PR | Tires No. | 6 |
Steel spring number | 9/12 | Front track(mm) | 1665 |
Fuel type | diesel | Rear track(mm) | 1525 |
Emission standard | Euro 4 | Gear box | 6 |
Cab | Single row, luxurious interiors and seats, the cab can rotate forward, with power steering, optional air conditioning |
Engine model | Engine manufacture | Displacement(ml) | Power(Kw) |
ISF3.8s4141 | Beijing futian commins engine Co.,Ltd | 3760 | 105 |
Truck cleaning suction performance |
Water Tank capacity(m³) | 3.5 | Sewage Tank capacity(m³) | 4.5 |
Main Characteristic |
1.The truck is a new type of sanitation special vehicles and integration of combined high pressure cleaning vehicle and the sewage suction truck,composed of two types of chassis, power takeoff, water tank, sewage suction sewage tank, high-pressure water pump, vacuum pump, hydraulic control device, mechanical cutter pulling device, high pressure washing pipeline, vacuum suction sewage pipes, sewage system composition. 2. High pressure pump vacuum pump imported from Italy, with the domestic well-known brand, sewage tank cover can be opened by the hydraulic tank, hydraulic lift operation, the tank dump was dumped directly through the dirt. |
