• Model NO.：Septic Tank
• Fuel：Diesel
• Tank Volume：3cbm Vacuum Sewage Tank 2.5cbm Jetting Water Ta
• Drive Wheel：4x2
• Hoesrpower：100-190HP
• Condition：New
• Drive Type：LHD,Rhd
• Dimension(L*W*H)(mm)：5255*1890*2410
• Tyre & Spare Tyre Spec：6.50-16
• Kerb Wt.：2550 Kg
• Wheelbase (mm)：2800, 3200
• Tank Material：Q235 Carbon Steel Optional Lined PE
• Clean Water Tank Capacity：0000 Litres
• Sewer Water Tank Capacity：3000 Litres
• High Pressure Pump：16MPa
• Vacuum Pump：Water Ring Pump
• Transport Package：Nil
• Specification：Cesspit Emptier Truck
• Trademark：Dongfeng
• Origin：China
• HS Code：8705999090
• Production Capacity：80000

Overview

Truck Specification

Chassis model

Forland

Cab

Forland single row cab, with power steering. Electronic flameout,without a/c

Driving Type

4*2 Left hand driving

Max Speed (km/h)

95

Overall dimension(mm)

4760*1600*1920

GVW( kg)

4000

Mass in working order ( kg)

1000

Wheelbase(mm)

2456

F/R track base (mm)

1506/1466

F/R overhang (mm)

1032/1668

Approach/Departure Angel

25/14

Tire

175/70R14(6+1)

Clutch

Single-plate dry diaphragm spring clutch

Steering

Hydraulic steering with power assistance

Gear box

5-speed

Bridge

Front axle

1T

Rear axle

3T

Enging

Model

LQ480

Fuel Type

Diesel fuel

Type

Water-cooled four-stroke,, direct injection, turbocharged

Exhaust(ml)

1800

Max output power/rotate speed (hp /rpm )

51

Max torque/rotate speed(N.m/rpm)

1.800L

Braking  system

Service Brake

Compressed air brake

Park Brake

Spring energy

Auxiliary brake

engine exhaust brake

Eletric system

24v



Sewage suction truck capacity from 3000 litres to 20,000 litres

Fecal suction truck capacity from 3000 litres to 10,000 litres



 septic tank truck, sewage suction truck, toilet truck,sewer truck, vacuum truck



Detailed Product Description

Right hand drive or left hand drive FOTON forland 4x2 3000Liters 4000Liters vacuum tank sewage suction truck hot sales



Vehicle information list

Truck brand

Forland

Truck model

BSX5040GXW

Total mass

5980

Tanker volume

4000L

Rated mass

3000

Vehicle size

5255×1890×2410

Curb weight

2550

Cabin seat

2

A/D angle

23/17

F/R hang

1090/1365

Axles

2

Wheel base

2800

Axles loading

1480/2500

Max speed

90





Chassis information list

Chassis model

BJ1043V8JD5-S1

Tyre quantity

6

Tyre size

6.50-16

Leaf spring quantity

7/7+5

Front track

1415,1510

Fuel type

Diesel

Rear track

1425

Standard

Euro III

Engine model

4D22E

92HP

Displacement/power

2540ml/67kw

Material: -



 Carbon Steel

Capacity of the tank



3 m3

type



Cylindrical, thickness of the tank 5 mm. The container is equipped with splash walls and reinforced around it's circumference by U-profiles

over pressure.

0.5 bars

Inclination

towards the rear

Construction

completely welded,full welding

Indicator mark level of the sewage on the tank

for maximum and minimum

Tailgate

tightly locked with bolts, can be opened over the whole section laterally for maintenance and cleaning purposes. It shall be equipped with four inspection glasses

.Valve



Four way cock for suction and pressure, protection valve in front of vacuum pump

Drive



Direct drives from power take off Mechanically or Hydraulically.

Filling level indication



by sight glass including mechanical clearing connection mounted right in front of the tank

If there is additional indication systems takes the priority

Vacuum pump

Rotary type Air cooled





Capacity

300 m3/h



Location

between the cab and tanker or at the side of the tanker

Suction(Lifting capacity

minimum 0.2 m³ per minute at a depth of not less than 10 meter

 Drives

Direct from power take off.

Suction and pressure system  non return valve

DN 80, non-return valve and silencer in the pressure line

valve

Four-way-cock for suction and pressure manually controlled

safety valve

for maintenance of the pressure.

.



Corrosion-resistance ball float valve with one ball at the highest point of the sludge tank.

Safety pot with cyclonic cleaner. Easy maintenance by special cleaning door

Ball float valve in the safety pot

Fine mesh filter in the suction part of the vacuum pump with easily inter changeable rust proof filter element

Oil filling at the end of the pipe

High capacity cyclone between sewage tank and vacuum pump

Two hose trays

L=3200mm(volume according to space) open, made of galvanized steel, are fitted at the right-and-left-hand side



 Suction hoses

oil resistance,light,Flexible heavy duty suction hose,L=3 meters, dia100 mm,14PCS

Connection

efficient, airtight and have simplified design, compatible with couplings on truck.



Hose retainer located in the tank sides.



4000liters Forland Small Fecal Tanker Truck



Chassis model



BJ1043V9JE6-MS

Dimensions

mm

5990*1990*2350

Fact cubage

cbm

4

Engine

(Weichai Power Co., Ltd)



CA4DC2-10E3

(Euro3 emission standard)

Exhaust & engine power



3168ml, 76kw

Max speed



90km/h



Mass in working order

kg

2755

G.V.W

4400

Axle load

1760/2640

Wheel base



mm

3200

F/R track base

1590/1525

Suspension

1100/1620

Approach/departure angel

°

23/17

Tire specification



6.50-16, 6.50R16, 7.00-16, 7.00R16

Number of axles



2

Basic equipment of sludge tank  truck

Imported vacuum pump, power-take-off, hydraulic cylinders, control valves , pressure gauge,

 water gas separator , oil water separator, level inspection window, suction hose,pipeline system,etc.

1.Tank can be lifted hydraulically to 40 to 45 degree.Rear door can be opened&closed

 hydraulically. With full opening design, discharge can be very quick&complete.



2.Overfill system with music horn is equipped to prevent the vacuum pump damage from sewage water into vacuum pump when the tank is full.



3.Super power of vacuum pump, seamless die casted sheel cover, designing for container  with high ability of pressure-resistance,double hydraulic jack system, morestrength then cesspit

emptier.

  brand new high pressure vacuum suction truck



Certifications

Packaging & Shipping

FAQ

1.Are you trading company or manufacturer ?

We are Group Corporation manufacturer ,have Group Factories Contractor.

2 .Can I have samples of this type of product to test the quality?
Yes, you can buy any sample to test the quality,our MOQ is 1 unit.

3. What's the delivery time and can you lower the price?
It depends on your order.The delivery time is within 30 workdays after we received your prepayment. If you have placed an order of large quantities, then,of course, the price can be lowered.
 4.Can you supply some quick-wear parts? Yes, we can supply the parts as your request,such as traction,traction pin,balance beam and plate spring,hanging accessories,turntable,all kinds of brake pads,brake pan, bearings,etc.
 6.Do you have any used products for sale? We have products in stock for choices,the prices are favorable,we'll show you our stock products if you need.
7.What's the payment terms?TT 30% as deposit, balance before shipment by TT or at sight.

8. How to guarantee customers get the goods smoothly after they payment?
Don't worry,dear.We have joined the trade assurance,you can place the order by trade assurance,if we don't delivery products, the deposit will be returned to you.
9.How can you ensure the quality of the products?

Don't worry,dear.We have joined the trade assurance,if the products have quality problems when you received them,the payments can be refund to you.


Looking forward to receiving your inquiry!
