• Model NO.：Water Tanker
• Transmission Type：Manual
• Payload：20T
• Fuel：Diesel
• Drive Wheel：6×4
• Horsepower：150-250hp
• Condition：New
• Tire：11.00r20
• Engine：Dongfeng Cummins Engine
• Overall Dimension (mm)：9880X2480X3050
• Wheel Base (mm)：4350+1300
• Tank Material：4-6mm Carbon,Stainless Steel
• Fire Monitor：Model: PS50 Rate of Flow: 60L,S,1MPa, Water Range
• Fire Pump：CB10,60,Rate of Flow:60L,S, Pressure:1.0MPa
• Transport Package：Nil
• Specification：milita ry standard.
• Trademark：DFAC
• Origin：China
• HS Code：8705309000
• Production Capacity：10000

Specification of DF Sprinkler Truck / Watering CartItemSpecificationItemSpecificationGeneralTruck NameSprinkler truck / Watering CartOverall Dimension (mm)9880x2480x3050Truck BrandDongfengGross / Curb Weight (kg)25000/10370Truck ModelEQ1258KB3GJApproach / Departure Angle (°)24/11Max. Speed (km/h)90Front / Rear Overhang (mm)1250/2980ChassisChassis BrandDFChassis ModelEQ1258KB3GJWheel Base (mm)4350+1300Leaf Spring9/10Traction System6 x 4Quantity of Axles3Cab Capacity1+1Front / Rear Axle Load (kg)7000/18000TransmissionmanualFront / Rear Wheel Tread (mm)1960/1860Tyre Model11.00-20 18PRQuantity of Tyre10+1Engine (Motor)BrandDFType of FuelDieselModelISD210 50Displacement (ml)6700Max. Power (hp)210Emission StandardEuro 3-5-6Motor Net Weight (kg)*ABSyesEquipmentsTank Capacity (L)20,000Tank Material4-6mm carbon/stainless steelFire MonitorModel: PS50 rate of flow: 60L/S/1MPa, water range: ≥60mFire Pump(Normal Pressure)middle-lower pressure is optional

1. Normal pressure model:: CB10/60,rate of flow:60L/s, pressure:1.0MPa

2.water diversion time ≤35s (7m absorbing depth) water ring sandwitch type full power PTO

REMARKS:



1. Equipped with high power self-suction water pump that characterized by high-pressure and fast speed suction.

2. Equipped with front, rear and side sprinklers and high position sprinkler, and rear working platform.

3. The water cannon which is installed on the working platform can rotate by 360 degree and the water flow can be adjusted into various rain shape. There are straight shape, heavy rain, moderate rain and drizzle etc. The max range can reach 30m.

4. Equipped with fire coupling, flow valves, filter screen and water level gauge.

5. According to customers' request, the crane, high working platform and spraying machine also can be equipped.

6. Mainly used for washing on urban roads, watering and greening on trees, green belts and lawn and dust full of construction sites. And also used for drinking water delivery and fire fighting function etc.



NOTE:

1. Any part can be customized depending on customers' demand.



2. 12 months whole vehicle warranty



3. We could support you original spare parts. Besides, we can give assistance in the following days by email or telephone. If necessary, our outwork engineer could go for technical assistance.






Similar Keywords: foam truck tanker, fire fighting tank truck, fire and rescue truck, fire appliance, fire engine, fire apparatus, fire truck tank, fire service truck, fire fighting vehicle
