• Model NO.：Water Tanker Truck
• Payload：4t
• Fuel：Diesel
• Drive Wheel：4×2
• Horsepower：＜150hp
• Condition：New
• Tire：7.00r16
• Engine：Cy4100q
• Overall Dimension (mm)：5990X 1960X2380
• Wheel Base (mm)：3300
• Tank Material：4-6mm Carbon,Stainless Steel
• Fire Monitor：PS20, Rate of Flow:20L,S,1MPa,Water Range:≥45m
• Fire Pump：CB10,20,Rate of Flow200L,S, Pressure:1.0MPa
• Transport Package：Nil
• Specification：mil itary standard.
• Trademark：DFAC
• Origin：China
• HS Code：8705309000
• Production Capacity：10000

Main informationProduct Name: Dongfeng Water TruckItme No. DRZ5070GSSLChassis No. EQ1060Overall Sizemm6070×2020×2400Total Weight:kg7495Curb weight:kg3480Cab-by the number :people2,3Approach/departure angle°28/16Front/rear suspensionmm1070/1700Number of axlespcs2Wheelbasemm3300Front / Rear treadmm1750/1586Maximum speedkm/h90Tire Specification 7.00-16Function parameterWater Tank Volumecbm4Tank Material Carbon SteelBasic Equipment front and rear sprinkler, working platformEngine informationModel CY4100Brand Dongfeng Chaochaipowerkw/hp82Emission Level Euro 3



The pictures are for your reference only.DRZ Fire Sprinkler Water Tanker TruckItemSpecificationsItemSpecificationsTruck ParameterModelDRZ5070GSSEChassis ModelEQ1060GLJGross Weight (kg)7300Overall dimensions (mm)5990 * 1960 * 2380Payload Weight (kg)4000Tank Volume(cbm/t)4Curb Weight (kg)3150Wheelbase (mm)3300Engine ParameterModelCY4100QBrandDongfengPower(hp/kw)82 / 60Emission LevelEuro 3SpecificationMax speed (km/h)95Front Track (mm)1404Cab2Rear Track (mm)1458Leaf Spring6/8+4Front/Rear Overhang (mm)1032/1658Number of Tyres6Approach / DepartureAngle(°)16/13Tyre Specification7.00R16Axle Load (kg)2920/4380Number of axles2  Special FunctionTank Capacity (L)4000Fire MonitorModel:PS20, rate of flow:20L/S/1MPa,water range:≥45mFire Pump(Normal Pressure)middle-lower pressure is optional1. Normal pressure model::CB10/20,rate of flow200L/s, pressure:1.0MPa2.water diversion time ≤35s (7m absorbing depth) water ring sandwitch type full power PTO
