Specialized Vehicle

HOWO Road Sweeping Truck 4X2

Shandong Shanglong Economic and Trade Corporation Ltd.
  • Type:Pure Sweep-type
  • Transmission Type:Manual
  • Emission Standard:Euro 3
  • Fuel:Diesel
  • Payload:10t
  • Use:Burnishing

Base Info

  • Model NO.:ZZ1257M5247
  • Cleaning Process:Cold Water Cleaning
  • Condition:New
  • Weeping Capacity:About 45000m2,H
  • Sweeping Width:More Than 3m
  • Transport Package:Nude
  • Trademark:SINOTRUK
  • Origin:China
  • HS Code:8701909000
  • Production Capacity:1000,Month

Description

SINOTRUK HOWO  Road sweeper truckItem No.Parameters Overall Dimension6190*2090*2500 mmDrive model4x2, new condition , LHDGross weight 7360 kgCurb Weight5950kgWheel Base3360 mmFront/rear Overhang1160/1670 mmFront/rear Tread1805/1595 mmApproach/Departure Angle19/15 degreeEngineYUNNEI ENGINE, YN4100, Diesel Engine, Four Stroke,
Cylinder in line.Engine horsepower110 HP , Euro IIDisplacement3.612 L(Diesel)Max Driving Speed90 km/hGear BoxWLY6T100,6 Forward Gear, 1 Backward GearTire7.00-16,  6 pieces with 1 spare tire.
Upper part of the road sweeper truckTankGarbage tankTank materialStainless steel 304Tank volume(cbm)4.0 cbmWater tankTank materialStainless steel 304Tank volume(cbm)1.5 cbmAuxiliary engineModelJMC Brand  JX493G modelPower(kw)57 kw, 77.5 HPMotorBrand Imported Italian brand motor Switch of operationBrandImported French  brand switchBrushQuantity(pc)4 pcsDiameter of brush850 mmWorking area(m)3.0-3.5 mOperation detailWorking speed3-35 km/hWorking width2.8-3.2 metersMax. Operation ability 45000 m2/hMax. Sucking dimension100-120 mmSweeping rate95%Brush extend dimension400 mmHydraulic system Model Electrical control type.Pressure of hydraulic system16 MpaVolume of the hydraulic oil tank60 LTemperature of hydraulic oil60°Main partPump, hydraulic motor, hydraulic cylinder and electromagnetic valveRemarks1, With water sprayer-bar
2, Rear vacuum cleaner
3, Blower
4, Rear LED pilot lamp
5, Self unloading box body
6, The color will be designed on basis of your requirements.
HOWO Road Sweeping Truck 4X2HOWO Road Sweeping Truck 4X2
