• Model NO.：ZZ1257N4641W
• Fuel：Diesel
• Drive Wheel：8X4
• Engine Capacity：＞8L
• Condition：New
• Color：Optional
• Transport Package：Nude Packing
• Specification：10450*2550*3350mm
• Trademark：SINOTRUK HOWO
• Origin：China
• Production Capacity：1000 PCS Per Week

Chassis ModelZZ1257N4641WDriving Type4X2,6X4,8X4Cabin HW76, with one sleeper and two seats, double arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer, with four piont support floating suspension+shock absorber.Engine Make: SINOTRUK
Diesel 4-stroke direct injection diesel engine
Engine model: WD615.69, 336 HP ; WD615.47, 371HP ;WD615.87,290HP;
Emission :Euro 2
6-cylinder in-line with water cooling, turbo-charging and intercooling
Displacement: 9.726 L Transmission HW19710, 10F & 2R with PTO Steering ZF power steering, modol ZF8118, hydraulic steering with power assitanceFront Axle HF9,1x9000 KGS
Steering with doubleT-cross section beam Rear Axle HC16, 2x16000 KGS
Pressed axle housing, central single reduction with hub reduction,with differential locks between wheels and axles.
Ratio:4.42Propeller Shaft Double universal joint propeller shaft with gear-shaped coupling flangeChassis Frame: Uprofile parallel ladder frame with section of 300x80x8mm,reinforced subframe all cold riveted cross members
Front suspension:10 semi elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer
Rear suspension:12 leaf semi elliptic springs, bogie spring and stabilizerBrake Service brake: dual circuit compressed air brake
Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels
Auxiliary brake: engine exhaust brakeElectrics Operating voltage: 24 V, negative grounded
Starter: 24 V, 5.4 Kw
Alternator: 3-phase, 28 V, 1500 W
Batteries: 2 x 12 V, 165 Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse lightTyres315/80R22.5, tubless tires with one spare tireFuel Tank400LTank BodyVolume 20CBM, Side 5mm, Cover 6mm, with front and rear sprinkler system;Overall Dimension  10450*2550*3350mm
