Dongfeng Offroad 4X4 Aerial Platform Truck 12-16m
Hubei Dong Runze Special Vehicle Equipment Co., Ltd.- Type:H
- Certification:ISO9000, CCC
- Emission Standard:Euro 3
- Hoesrpower:120~140
- Payload:7t
- Fuel:Diesel
Base Info
- Model NO.:OEM
- Transmission Type:Manual
- Drive Wheel:4X4
- Condition:New
- Tire:7.50r16lt
- Cabin:Duolika
- Fuel Tank(L):300L
- Drive:LHD , Rhd
- Work Lift Height:12m
- Boom Crane Loading Capacity:1000kg
- Wheelbase (mm):3800
- Engine:120HP
- Transport Package:Nil
- Specification:military standard.
- Trademark:Dongfeng
- Origin:China
- HS Code:8705909990
- Production Capacity:10000
Description
SPECIFICATIONS FOR DONGFENG HYDRAULIC AERIAL LIFT PLATFORM VEHICLE 20 M Product Name Dongfeng 20 M aerial hydraulic lift platform vehicle Product Model NO. DRZ5080JGK20E5 Function High altitude Operation General Situation of Vehicle Overall Dimension(MM) 8100×2320×3350 Curb Weight(Vehicle) (KG) 7640 Dimension of Loading space (MM) / Loading Capacity(KG ) 200 GVW.(KG) 7835 Fuel Type Diesel Transmission Type Manual Condition New Maximum Speed (KM/H) 103 Cab 3 Persons Chassis Specification Chassis Brand Dongfeng Chassis Model NO. EQ1080SJ8BDC Driver's Seat Direction Left Side Drive Drive Form 4*2 Steering System Steering wheel Brake System Air braking Gear Box 5-Speed ABS Include Electric System 24V Axle Load(KG) 3300/4975 NO. of Axles 2 Tyres Specification 7.50R16 Whee Base(MM) 3800 NO. of Wheels 6 Overhang F/R (MM) 1130/2460 NO. of Spring Leaf Engine Specification Engine Model NO. CY4SK251 Engine Power (KW/HP) 115/156 Displacement(ML) 3856 Emission level Euro 5 EGR Upper Body Configuration Main Material: Carbon steel Q235,
Upper Body And Chassis Connection Way: Weld and bolt connection,
Max.Working Height: 20 M,
Max Working Radius: 9M, 360° rotation,
Prop Leg Max.Span : Lengthways :2430MM;Crosswise: front 1600MM, Rear:2780MM, adjustable;
Load of Aerial Working Platform: ≤200 KG,
Dimension of Aerial Working Platform: 1080X610X1100MM Product Feature 1.Three Foldable arms,arms is electrically controlled,speed is adjustable;
2.Hydraulic Cylinders control the boom arm stretching,lifting or retracting,and can be lockable;
3.Double station operation,up and down interlock;
4.Engine start and stop can be remote controlled;
5.Crane hook can be mounted if required,Max.Lifting Height: 11.5M,
Max Lifting Weight: 1000 KG
PACKING & DELIVERY
Truck mounted aerial platform, which will be used to clean pole mounted solar panels for street lights. So it requires a special arrangement of truck mounted water tank as well as water hose at the basket.
The pole height is 6M so aerial lift should be 8-10M.
Water tank capacity can be 3000Ltr
Truck may be medium light truck of 3.% ton.
Welcome all around world customer visit our factory
Upper Body And Chassis Connection Way: Weld and bolt connection,
Max.Working Height: 20 M,
Max Working Radius: 9M, 360° rotation,
Prop Leg Max.Span : Lengthways :2430MM;Crosswise: front 1600MM, Rear:2780MM, adjustable;
Load of Aerial Working Platform: ≤200 KG,
Dimension of Aerial Working Platform: 1080X610X1100MM
2.Hydraulic Cylinders control the boom arm stretching,lifting or retracting,and can be lockable;
3.Double station operation,up and down interlock;
4.Engine start and stop can be remote controlled;
5.Crane hook can be mounted if required,Max.Lifting Height: 11.5M,
Max Lifting Weight: 1000 KG
PACKING & DELIVERY
Aerial platform truck 16m water tank and water pump ,Truck Mounted Aerial Work Platform water tank,Work Platform water tank truck,aerial bucket truck water tank,bucket truck with water tank ,Truck Mounted water tank Aerial Work Platform
Truck mounted aerial platform, which will be used to clean pole mounted solar panels for street lights. So it requires a special arrangement of truck mounted water tank as well as water hose at the basket.
The pole height is 6M so aerial lift should be 8-10M.
Water tank capacity can be 3000Ltr
Truck may be medium light truck of 3.% ton.
Welcome all around world customer visit our factory
